"YUME - iXi" Installation Instruction
■ YUM E-iXi
AY-YMIXILGL1US YUME-iXi ／Ltype／GL1（WHITE）
GL2
YUME-iXi ／Ltype／GL2（BLACK）
GL3
YUME-iXi ／Ltype／GL3（DARK BROWN）
GL4
YUME-iXi ／Ltype／GL4（MAROON）
AY-YMIXIHGL1US YUME-iXi ／Htype／GL1（WHITE）
GL2
YUME-iXi ／Htype／GL2（BLACK）
GL3
YUME-iXi ／Htype／GL3（DARK BROWN）
GL4
YUME-iXi ／Htype／GL4（MAROON）
The precautions listed here are to ensure that YUME-iXi can be installed safely, and to prevent any danger or risk to the person installing
YUME-iXi or those around them.All of these precautions are important for safety. Takara Belmont is not responsible for any damage or risk
to the person installing YUME-iXi or those around them due to accidents if YUME-iXi is installed without adhering to the precautions.
Caution
If YUME-iXi is installed after ignoring this symbol,
"there is the risk of light or moderate injury or physical damage".
Note : Plumbing should be performed by a qualified technician and should meet all national and local plumbing codes and ordinances.
It is the responsibility of purchaser and/or plumber to conform to national and local codes and ordinances.
Takara Belmont does not take any responsibility or liability for plumbing and installation.
(
)
Image is of
AY-YMIXIHGL*US
1
Contents
To the installer
• The instructions should be thoroughly read
and understood before installation to ensure
that YUME-iXi is installed correctly.
• After installation, give these instructions to the customer.
To the customers
• Customers must ask professional to install YUME-iXi.
• Customers must not install YUME-iXi by themselves.
• Customers must store these instructions in
a safe place so as not to lose them.
* The actual shape of YUME-iXi and the images and
dimensions listed in these instructions may be modified
and are subject to change without notice.
Version 5
2
3
4
5
7
8
10
12
13
14
15
16
17
18
May 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont YUME-iXi
Summary of Contents for Takara Belmont YUME-iXi
-
Page 1: Table Of Contents
The precautions listed here are to ensure that YUME-iXi can be installed safely, and to prevent any danger or risk to the person installing YUME-iXi or those around them.All of these precautions are important for safety. Takara Belmont is not responsible for any damage or risk to the person installing YUME-iXi or those around them due to accidents if YUME-iXi is installed without adhering to the precautions. -
Page 2: Before Installation
Before installation Installation of pipes The following are important points to adhere during the installation of pipes. Read through the details carefully and ensure that the pipes are installed correctly. When installing this product, ensure that installation of pipes adheres to the instructions. Installing pipes without reading through the precautions will mean water may not mix properly, and a set temperature will not be achieved. -
Page 3: Usage Conditions
1-1/2" ; pipe risers from floor; rise dimensions : 3" If the floor surface is tiled, cracks may occur when fastening the bolts during installation of the YUME-iXi main body. If this looks likely to happen, use the main body attachment diagram and template as a reference and change the material of the attachment area that is in contact with the floor to another such as plywood or mortar. -
Page 4: Content Of Packaging
Content of packaging Basin Unit [Option] □Basin Unit □Basin side carriage jig □Chair side carriage jig [Ｈtype] □Maintenance Cover □Step □Head pillow □Neck cushion …2 [Ｌtype] □Maintenance Cover（small） □Step (low) □Drain cap □Hair catcher □Mohair tape （※Spare parts.） □Pipe packing □Screw Set for Cover □Sponge M4×10: Truss-head screw（black）... -
Page 5: Carrying The Main Body
Carrying the main body ■Carrying the Basin Unit Detach the basin unit from the skid. 〇While supporting the basin with hands, remove the hexagonal head bolts (phillips head)(M8 x 50mm) from the unit base (four locations). Do not remove Caution ・... - Page 6 ＜Basin side carriage jig＞ ① Temporarily remove the bolt on the right side of the carriage jig. ② Insert the bolt for the left side of the carriage jig into the position alignment hole. ③ Attach the right side of the carriage jig to the frame using the removed bolt.
-
Page 7: Installation Of Basin Unit
YUME-iXi or water seeping on the floor in the event of water leaks. • If pipe packing is not used, condensation may cause water to pool on the floor, structural parts may start degrading and malfunctions may occur. -
Page 8: Piping
Piping ２ [Before piping installation] “Hair trap” ,“Drain hose”,“Turn valve” and “Flexible pipe” is not included. Prepare those parts that suited the local statute. １、Attach drain hose to a hair trap and installed drain pipe. Drain hose pass through in the hole of sheet metal parts. Caution Follow a local rule, when you attach piping. - Page 9 3 Test water flow (1) Is there no water leaking from the pipe joints? The pipe joints may come loose during transportation, Caution so check the joints within the bowl thoroughly. Always test the water flow to prevent (2) Are the hot water supply and water supply pressures accidents during use.
-
Page 10: Installing The Step
Installing the Step Install the step to the basin unit. ① Check that the step shim is attached with tape to the ② Remove the screws fixing the legrest. bottom of the slide rail. (M6 x 15, 2 screws) Slide rail Step Step shim ③... - Page 11 ※If, in the procedure on the previous page, the bottom screw positions do not align, use the procedure below. ⑥ Leave the slide rail temporarily attached by loosening the truss-head screws on the top of the step slide rail. (M6 x 15mm, 2 screws) ⑦...
-
Page 12: Attaching The Seat Part
Attaching the Seat Part Attach the screen sheet to the base side cover. Velcro Screen sheet Attach the legrest. 2 locations Attach the leg rest using hexagonal head bolts. (M6 x 15mm, 2 bolts) Legrest Attach the edge of seat to the legrest by velcro. Place the back support cusion on the seat. -
Page 13: Procedure For Swapping The Reclining Pedal From Left To Right
Procedure for swapping the reclining pedal from left to right. This product has a reclining pedal on its left side. Depending on the salon layout, if it is necessary to install the reclining pedal on the right side, then swap the position of the reclining pedal from left to right in accordance with this manual. -
Page 14: Attaching The External Covers
Attaching the External Covers Attach the trap cover to the basin unit. The trap cover is fitted into the screw section at the bottom of the cover bracket under the basin, and can be attached Trap cover using urea cosmetic nuts in 2 locations. Push inwards ①... -
Page 15: After Installation
After installation ●Inspection Inspect the following items. Caution Be sure to execute the inspection without fail to prevent accidents during operation. (1) Check that there are no missing screws or other parts. (2) Check that there are no loose parts on the shampoo unit or the chair. If any part of the shampoo unit or the chair is loose, check the bolts at the joints again. -
Page 16: Dimensions
Dimensions Outline drawing (Unit :inch) H:When operated from standing position L:When operated from seated position ■ Top View End of chair Recommended min.spase of 99 (min:93 1/8) for standing position) Wall surface Min:3 or furniture Wall surface or furniture Bolt Anchor Point ×6 Drain position 1/2"）... -
Page 17: Unit Fixing Position And Plumbing Layout
Unit fixing position and plumbing layout Outline drawing (Unit : inch) H:When operated from standing position L:When operated from seated position Recommended minimum distance between product center and wall (furniture, etc.) is 33(applicable when passage is 20 wide) -
Page 18: Memo
ＭＥＭＯ... - Page 19 ＭＥＭＯ...
- Page 20 NOTE TAKARA BELMONT CORPORATION U.S.A 101 Belmont Drive. Somerset,NJ 08873 800-526-3847 JAPAN 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan 1E043YA0 Book Number...
