6.0 Electrical connections
Electrical connections must
be
made
by
a
qualified
compliance with all relevant codes. This
machine must be properly grounded to help
prevent electrical shock and possible fatal
injury.
The JWL-1840EVS lathe requires 230-volt single-
phase input.
As received from the factory, the JWL-1840EVS is
ready to run at 230-volt operation. This tool is
intended for use on a circuit that has an outlet that
looks like the one illustrated in Figure 6-1. The tool
has a grounding plug that looks like the plug
illustrated in Figure 6-1. Make sure the tool is
connected
to
an
outlet
configuration as the plug. No adapter is available
or should be used with this tool. If the tool must be
reconnected for use on a different type of electric
circuit, the reconnection should be made by
qualified service personnel; and after reconnection,
the tool should comply with all local codes and
ordinances.
IMPORTANT: The JWL-1840EVS Lathe cannot be
run on a GFCI circuit.
Figure 6-1: grounding
Before connecting to power source, be sure switch
is in off position.
It is recommended that the lathe be connected to a
dedicated 15 amp circuit with a circuit breaker or
fuse. If connected to a circuit protected by fuses,
use time delay fuse marked "D".
take precedence over recommendations.
6.1 GROUNDING INSTRUCTIONS
This tool must be grounded. In the event of a
malfunction or breakdown, grounding provides a
path of least resistance for electric current to
reduce the risk of electric shock. This tool is
equipped
with
an
electric
equipment-grounding conductor and a grounding
plug. The plug must be inserted into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
electrician
in
having
the
same
Local codes
cord
having
an
10
Improper connection of the
equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service person if you are in doubt
as to whether the outlet is properly grounded.
Do not modify the plug provided with the tool –
if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
The conductor with insulation having an outer
surface that is green with or without yellow stripes
is the equipment-grounding conductor. If repair or
replacement of the electric cord or plug is
necessary,
do
not
connect
grounding conductor to a live terminal.
Use only 3-wire extension cords that have 3-prong
grounding plugs and 3-pole receptacles that accept
the tool's plug.
Repair
or
replace
damaged
immediately.
A lightning strike or power
surge may cause inverter failure. When lathe is
not in use, disconnect power plug, or have a 3-
or 4-pole disconnect installed on the power
side.
6.2 Extension cords
The use of extension cords is discouraged; try to
position equipment within reach of the power
source. If an extension cord becomes necessary,
be sure it is heavy enough to carry the current your
product will draw. An undersized cord will cause a
drop in line voltage resulting in loss of power and
overheating.
Table 1 shows recommended size to use
depending on cord length and nameplate ampere
rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
Ampere
Total length of
Volts
Rating
cord in feet
120
25
Not
More
240
50
More
Than
Than
00
06
18
06
10
18
10
12
16
12
16
14
Extension Cord Recommendations
Table 1
the
equipment-
or
worn
cord
50
100
150
100
200
300
AWG
16
16
14
16
14
12
16
14
12
Not
12
Recommended
