Introduction to the ADS704X-5XEVM
Figure 2-6. Buffer Amplifier Circuit on the ADS704X-5XEVM
The buffer amplifier in
Figure 2-6
inputs and the AVDD/2 resistor divider (R7 and R9) from loading the ADC inputs (see
2.1.1, VBIAS sets the driver amplifier common-mode voltage for both signal paths. AINM is only required if U3 or
U5 in
Figure 2-2
is populated with the ADS7043. This specific ADC has a pseudo-differential input that requires
the AINM pin to be set to AVDD / 2 ±100 mV.
When the ADS7043 is used on the ADS704X-5XEVM:
Populate R39 in
Figure 2-4
Populate R45 in
Figure 2-6
Depopulate R40 in
Figure 2-2

2.3 Digital Interface and Communication

The EVM interfaces with the PHI and communicates with the computer over the USB. There are three devices
on the EVM with which the PHI communicates: the two ADCs (over SPI) and the EEPROM (over I
EEPROM comes preprogrammed with the information required to configure and initialize each ADC populated
by default on the ADS704X-5XEVM. Therefore, communication with the EEPROM is only required if the user
removes and replaces one of the default ADCs. See
All ADCs supported by the ADS704X-5XEVM use SPI serial communication in mode 1 (CPOL = 0, CPHA
= 1). The ADS704X-5XEVM offers 49.9-Ω resistors between the SPI signals to aid with signal integrity (see
Figure
2-2) because the serial clock (SCLK) frequency can be as fast as 60 MHz. Typically, in high-speed SPI
communication, fast signal edges can cause overshoot; these 49.9-Ω resistors slow down the signal edges to
minimize signal overshoot. JP5 provides test points to measure the digital signals, as illustrated in
8
ADS7042EVM-PDK, ADS7049-Q1EVM-PDK, and ADS7057EVM-PDK
Evaluation Module
C25
OPA_VDD
100nF
2
1
AVDD/2
3
U10A
OPA2320AIDGKR
AGND
U10B
AVDD/4
5
OPA2320AIDGKR
7
6
OPA_VDD
prevents the AVDD/4 resistor divider (R3 and R5) from loading the amplifier
with a 0-Ω resistor
with a 0-Ω resistor
Section 2.4
Copyright © 2021 Texas Instruments Incorporated
AGND
R45
AINM
DNP
0
VBIAS
for more information.
www.ti.com
Figure
2-4). As per
Section
2
C). The
Figure
2-7.
SBAU382 – NOVEMBER 2021
