1 ADS704X-5XEVM-PDK Overview

The ADS704X-5XEVM-PDK is a platform for evaluating the performance of the
ADCs. The ADS704X-5XEVM-PDK includes the following features:
• ADS704X-5XEVM for diagnostic testing and accurate performance evaluation of each ADC on the board
• USB powered—no external power supply is required
• A precision host interface (PHI) controller that provides a convenient communication interface to each ADC
over USB 2.0 (or higher) for power delivery as well as digital input and output
• Microsoft ® Windows ®
• Easy-to-use evaluation software for 64-bit Microsoft® Windows®
• A software suite that includes a graphical user interface (GUI) and tools for data capture, histogram analysis,
and spectral analysis. This suite also has a provision for exporting data to a text file for post-processing
The PHI board primarily serves three functions:
• Provides a communication interface from the EVM to the computer through a USB port
• Provides the digital input and output signals necessary to communicate with each ADC
• Supplies power to all active circuitry on the ADS704X-5XEVM board
Each ADS704X-5XEVM board includes the peripheral analog circuits and components required to extract
optimum performance from the ADC. Moreover, each ADS704X-5XEVM includes two complete ADC signal
chains: one that supports a single-ended input ADC (see
input ADC (see Section 2.1.2).
EVM Name
ADS7042EVM-PDK
ADS7049-Q1EVM-PDK
ADS7057EVM-PDK
Additionally, the ADS704X-5XEVM includes the following features:
• External signal source from subminiature version A (SMA) connectors or header pins
• Option to use external power supplies
• Serial interface header for easy connection to the PHI controller
• Pin connections to monitor digital signals with a logic analyzer
• Two ultra-low noise, low-dropout (LDO) regulators for excellent single-supply regulation of all analog circuits
• Accommodates all package options for 14 different ADCs using four different device footprints, as per
1-2
SBAU382 – NOVEMBER 2021
Submit Document Feedback
8 and Windows® 10 operating systems
Table 1-1 defines which ADCs are populated by default on each EVM.
Table 1-1. Default ADCs Populated on Each EVM Variant
Single-Ended ADC (U3)
Copyright © 2021 Texas Instruments Incorporated
Section 2.1.1), and another that supports a differential
ADS7042
ADS7049-Q1
ADS7042
ADS7042EVM-PDK, ADS7049-Q1EVM-PDK, and ADS7057EVM-PDK
ADS704X-5XEVM-PDK Overview
ADS704x and ADS705x family of
Differential ADC (U5)
ADS7057
ADS7047
ADS7057
Table
Evaluation Module
