ADS704X-5XEVM-PDK Overview
Supported ADC
ADS7040
ADS7041
ADS7042
ADS7043
ADS7044
ADS7046
ADS7047
ADS7052
ADS7054
ADS7056
ADS7057
ADS7029-Q1
ADS7039-Q1
ADS7049-Q1
4 ADS7042EVM-PDK, ADS7049-Q1EVM-PDK, and ADS7057EVM-PDK
Evaluation Module
Table 1-2. ADCs Supported by the ADS704X-5XEVM
Populated on EVM?
n/a
n/a
ADS7042EVM-PDK,
ADS7057EVM-PDK
n/a
n/a
n/a
ADS7049-Q1EVM-PDK
n/a
n/a
n/a
ADS7042EVM-PDK,
ADS7057EVM-PDK
n/a
n/a
ADS7049-Q1EVM-PDK
Copyright © 2021 Texas Instruments Incorporated
Input Type Package Options (Designator)
Single-ended X2QFN (U8), VSSOP (U3)
Single-ended X2QFN (U8), VSSOP (U3)
Single-ended X2QFN (U8), VSSOP (U3)
Pseudo-differential X2QFN (U8), VSSOP (U3)
Differential X2QFN (U5), VSSOP (U9)
Single-ended
Differential
Single-ended
Differential
Single-ended
Differential
Single-ended
Single-ended
Single-ended
www.ti.com
X2QFN (U8)
X2QFN (U5)
X2QFN (U8)
X2QFN (U5)
X2QFN (U8)
X2QFN (U5)
VSSOP (U3)
VSSOP (U3)
VSSOP (U3)
