STEP 2A INSTALL HOOD ONTO WALL
IMPORTANT: Framing must be capable of supporting up to 150 lbs.
SKIP THIS STEP IF INSTALLING BENEATH A
SOFFIT OR CABINET, GO TO STEP 2B.
• Locate at least 2 vertical studs at the wood support.
then install 2 screws through the wood support into the
located ½" from the edge of the wood support.
below the 15-3/8" marked line.
15-3/8"
30"
to
36"
framing to secure the wood support to 2 studs.
IMPORTANT: Screws must penetrate at least 1" into
vertical studs. Countersink screws into support.
NOTE: The mounting
screws must remain
in their original
shipping location.
These screws are
positioned to engage
the keyhole slots in
the back of the hood.
12
Installation Instructions
Wood
Support
Centerline of
Installation
Space
Original Mounting
Screws as Shipped
1/4"
Gap
support until they protrude 1/4" forward. This 1/4" gap
will provide clearance to hang the hood.
• Use duct tape to seal the transition duct connection.
Check to be sure the damper moves freely.
Hang Hood On Wood Support
• Lift the hood and hold close to the installation location.
Route house wiring through the knockout and into the
mounting screws engage the keyhole slots in the back
of the hood. Tighten the screws.
30"
to
36"
• Install additional 4 screws to secure the hood to the
wood support.
• Drill 1/8" pilot holes into the two lower holes. If the pilot
washer and the screw from the wall anchor.
Centerline of
Installation
Space
