ADVANCE PLANNING
Ductwork Planning
• These vent hoods are equipped for 10" round
ductwork on the 48" wide hoods. 30" and 36" hoods
may be transitioned to 8" round.
• This hood may be vented vertically through upper
elbows to vent horizontally through the rear wall.
•
1. Minimize the duct run length and number of
transitions and elbows.
2. Maintain a constant duct size.
3. Seal all joints with duct tape to prevent any leaks.
• Use metal ductwork only.
• Install a wall cap or roof cap with damper at the
transition needed in advance.
air system in accordance with local building code
requirements. Visit Monogram.com for available
makeup air solutions (search on the words "make-up
air" or "make up air").
Wall Framing for Adequate Support
support must be provided. Hoods must be secured
to vertical studs in the wall.
• It is strongly recommend that the vent hood with
duct cover be on site before final framing and wall
finishing. This will also help to accurately locate the
ductwork and electrical service.
Decorative Duct Covers:
available to fit all models. The duct cover conceals
the ductwork running from the top of the hood to the
ceiling or soffit. Stack one or more duct covers over
the top of the hood to reach your ceiling height.
10
Advance Planning

POWER SUPPLY

IMPORTANT
TERRE.
Remove house fuse or open circuit breaker before
beginning installation.
Electrical supply
breaker or time delay fuse.
• If the electrical supply does not meet the above
proceeding.
• Route house wiring as close to the installation
location as possible on the back wall or ceiling.
• Connect the wiring to the house wiring in accordance
with local codes.
Grounding instructions
The grounding conductor must be connected to
equipment-grounding terminal or lead on the hood.
equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or
service representative if you are in doubt whether the
appliance is properly grounded.
conducteur de terre de l'appareil peut poser un risque
de choc électrique. Consultez un électricien agréé ou un
représentant du service de réparation si vous avez des
riesgos de descargas eléctricas. Consulte a un electricista
calificado o a personal del servicio técnico si tiene dudas de
que el electrodoméstico se encuentre conectado a tierra de
forma apropiada.
WARNING
AVERTISSEMENT
ADVERTENCIA
WARNING
The improper connection of the
AVERTISSEMENT
ADVERTENCIA
31-2000859 Rev. 0
