AKCP sensorProbe2 User Manual page 26

Ethernet MAC ID :- This is the MAC address of your unit. This is a read only field
Ethernet Duplex Mode :- The duplex mode and speed of your unit. This is a read only field also.
Ensure you apply your new settings by clicking on the "save" button.
Below this, there are some further settings for the time and date.
RTC Battery Status :- This field displays the status of the Real Time Clock battery on the unit. If
the status displays "Bad", you must replace the battery; otherwise, when the SP2, SP4 or SP8 do
not have mains power, the clock will stop running. Therefore, you must re-configure the system
time settings on every reboot.
Date and Time Settings :- Enter the new date and time in this field. The date and time use the
following format : date/month/year (dd/mm/yy) and hour:minute:second (hh:mm:ss)
Time Zone :- Select time zone that is corresponding to your location from this list box.
Use NTP :- An NTP (Network Time Protocol) is used to synch your units clock over a network.
There are many options in this list box. The details for each one are as follows:

Do Not Use NTP - select this option to turn off the time synchronization feature.

One Time - the time is synchronized once the Save button is pressed.

On System Start Up - the time is synchronized once the cameraProbe8 is turned on or
reboot.

Once a Month/Week/Day/Hour - the time is automatically synchronized every month,
week, day, or an hour, respectively.
NTP Server 1 and 2 :- Set the IP address of the NTP servers to be used. The NTP will
synchronize the time with the server that has less number of the stratum.
Updated until firmware 476 - 26 -
SP2/SP4/SP8/SP8-X20 Manual
