  • Page 1 SP1+ Introduction Manual User Manual - 2022 Copyright © 2022, AKCP...

  • Page 2: Table Of Contents

    (please use the Ctrl F “search” for locating the exact sections & pages) Table of Contents Introduction ............................. Port assignment information for SP1+ units’ info .................. LED information for SP1+ units ......................Reset button functions for SP1+ units ....................Setting up the unit’s IP address & troubleshooting - Dual Power Input Options ......... SP1+ Web UI Walkthrough ........................
  • Page 3 SNMP Server Integration Services SSL Certificate Modbus Password Checking and security Password Security options Maintenance (create support files & backups etc.) Heartbeat Messages License Management About Sensor’s page ..........................General options for all sensors Virtual sensors Example sensor configuration Temperature/Humidity Sensor Relay Sensor Firmware upgrade through the Web UI ..................

  • Page 4: Introduction

    ● Supports 1 Intelligent Sensors and 1 Dry Contact ● Notification Wizards ● Front and Rear Thermal Mapping for any server cabinet ● Virtual Sensors ● AKCP Swing Handle Lock support Please check all the specifications & features on our SP1+ datasheet: https://www.akcp.com/akcp-products/sp1-plus/ Important notes: A) Some of the pictures shown in this manual might not represent the actual Web UI of the SP1+ unit;...
  • Page 5 IP address on the unit. The SP+ F4 & F7 type units will not be affected. C) AKCP also always highly recommends using a dedicated 3rd party UPS on the units. Any damage caused by unstable power or power outages will void the warranty on our units.
  • Page 6 - 6 -...

  • Page 7: Port Assignment Information For Sp1+ Units' Info

    Port assignment information for SP1+ units Important note: • If you're using analog pins on the sensor port (with the manually on-lined DCV sensor, and pin 7 of the RJ45 connector) make sure that the voltage doesn't exceed 3 Volts. Otherwise you can damage the unit! New features on all H7 SP1+ units for no extra license fees include: •...

  • Page 8: Led Information For Sp1+ Units

    LED information for SP1+ units Power/Ethernet Link - Sensor 1 - Sensor 2 - Sensor 3 - Sensor 4 The Power/Ethernet LED will become red if there’s no network connection, and blinking green (according to LAN activity) when the connection is normal. LEDs Status: Power = Solid red when connected Ethernet = Should be green and yellow blinking (when accessing the web UI) for good connection.
  • Page 9 Time to hold Action < 3 sec Speak/show IP and broadcast its info (display on LCD sensor too, if connected) 3..7 sec Reboot (reset CPU) 7..12 sec Web UI password reset 12..17 sec Clear the sensor, notification and access DBs, logs Serial flash erase ( DB erase without factory reset, the system configuration is kept 17..25 sec...
  • Page 10 Additional Options for Connecting to your SP+ Units Web UI Option #1. If using DHCP check your network router's DHCP assignments list. How do I find the DHCP list on my router? (the following may be different depending on your router type) Click the Status tab after logging into your router, then the Local Network sub-tab.
  • Page 11 IP address and allow you to open the units web interface. Option #3. If you have our AKCP LCD display sensor. Connect the LCD display to any sensor port on the unit. The IP address will be displayed in the LCD panel.
  • Page 12 IMPORTANT NOTE: If you have performed a complete factory reset on your SP1+ H7 type (on firmware v1.0.5824 or higher) unit without choosing the option to retain the fixed IP address, then your unit will default back to DHCP. Please refer to the steps above again to determine your units newly assigned IP address.
  • Page 13 Or open an Administrator Command Prompt (CMD) window and type: netsh interface ipv4 add address “Local Area Connection” 192.168.0.2 255.255.255.0 The above command adds the IP Address 192.168.0.2 (with Subnet Mask 255.255.255.0) to the connection titled “Local Area Connection”. You will then be able to connect to the unit with its default IP. Note: The secondary IP address is permanent for the LAN connection;...
  • Page 14 SP1+ Dual Power Input Option SP1+ can be powered with dual inputs. PoE comes as standard, and an additional AC or DC source can provide primary power with PoE providing backup power. Or, in the absence of PoE dual inputs are available through our external DC-DC conversion box.

  • Page 15: Sp1+ Web Ui Walkthrough

    Important Note:- As Microsoft no longer supports the Internet Explorer web browser, we also do not support any version of IE when viewing our web interface on all AKCP base units. Please use the Chrome or Firefox browsers when viewing the base units web UI.
  • Page 16 This is the Summary page with Sensor Status and the Event Log, with the Temperature Sensor Graph enabled. Host Log The Host Log contains all entries from the “All Events” category. We’ll explain the different categories in the Notifications manual. The last 30 entries are shown, but if you’re scrolling down the list, more events (30 more) will be loaded automatically.
  • Page 17 Click on the configuration menu button directly next to the right of a sensor to access its popup menu. Directly acknowledge a sensor’s status, and put the sensor offline Control the relay-type sensors Enable/disable graph data collection per sensor (if they support it), and display the graph display window for the Summary page We’ll explain the Graph feature in more detail below.

  • Page 18: Graph Feature

    Graph feature After you’ve enabled the data collection for a sensor, you can choose to display specific time intervals of the stored data: hourly/daily/weekly/monthly and custom display interval. You can also export the recorded data in multiple formats. Important: The maximum number of enabled graphs per unit is 14. In this example picture, we’ve chosen to display the temperature sensor’s daily maximum.
  • Page 19 You can choose to export the graph data in selected formats by clicking on the graph’s menu on the right, then by choosing the desired format from the popup menu. The file will be downloaded automatically and assigned a file name that will contain the sensor’s name, IP address of the unit, and the date and time.
  • Page 20 - 20 -...
  • Page 21 Please use the link below to download the manual for setting up the maps on your sensorProbe+. http://www.akcp.in.th/downloads/Manuals/SP1+/sensorProbe+%20and%20WTG%20Map%20Manual .pdf If you find this limiting, you can also use our AKCPro Server for advanced mapping which can be downloaded from this link here: https://www.akcp.com/akcp-products/akcpro-server/...

  • Page 22: Important Notes On Custom Desktops

    Important Notes on custom desktops Please note the custom Desktops that are created ARE NOT stored in the SP+ units memory. These are HTML based, so they are stored in the browser cache, or local data on the Chrome & Firefox browsers.

  • Page 23: Managing Desktops

    Managing Desktops Navigation You can manually change between Desktops using the arrow menu, or by directly clicking on the desired Desktop if they are stacked under a folder. With this button, your current Desktop will expand to the browser’s screen width as shown on the screenshot below: - 23 -...
  • Page 24 Click it again to go back to the full view. - 24 -...
  • Page 25 On each Desktop and Folder item, you have the option to Rename, Move, Export or Delete them. Move is useful if you’ve created multiple folders (see below). As noted earlier, don’t forget to export your Workspace items to save them permanently. - 25 -...

  • Page 26: Folders

    Folders You can add Folders to arrange your desktops into a hierarchical view. After created, you can simply drag and drop your Desktops under the folder, or use the Move menu. The folder structure will also display on the Desktop selector menu on top: - 26 -...

  • Page 27: Desktops

    Desktops You can add new Desktops where you can customize the layout to place any sensor gadget, logs, graphs etc. on the screen. There are two ways to add a new desktop. The first is by creating a blank desktop using the Add Desktop link under the Workspace tab: Name the new desktop and click the Add button.
  • Page 28 In addition to the simple blank desktop, the second way to add a new desktop is via pre-defined Desktop Layouts. You could choose one that best suits your monitoring needs to drag and drop your sensor gadgets. Use the plus button at the top of the page and select the layout for your new desktop: Alternatively you can click on the Add Layout link to select from layouts: - 28 -...
  • Page 29 - 29 -...
  • Page 30 The empty desktop will have placeholders similar to this: As an example below, we’ve selected the 1+1+2 layout. Then you can drag and drop sensors, logs and graphs on the layout: Below we’ll show you how you can add sensors to the desktops. - 30 -...
  • Page 31 - 31 -...

  • Page 32: Adding Items To Your Custom Desktop

    To add items from the units that are connected to the SP+ unit, you will first need to click on the AKCP link in the Navigation Tree as shown above. Next simply drag and drop the items you wish to add to your new desktop. This is also how you can add items to the Summary page.

  • Page 33: Desktop Auto Scroll Feature

    Desktop Auto Scroll feature With this feature enabled, your desktop view will automatically switch between the created additional desktops within the specified time interval. You can also manually change between Desktops using the menu. - 33 -...

  • Page 34: Managing Rack Maps

    Managing Rack Maps The Rack Map feature was originally (and still is) included in the AKCess Pro Server / AKCPro Server (HTML5) and has also been added to the SP+ units. You can add a Rack Map as a graphical representation of your server rack, and to display and record the temperature of the airflow within your server cabinets.
  • Page 35 You can add Temperature sensors, the Swing Handle Lock and the Sensor Status Light gadget on a Rack Map. Simply drag and drop the desired sensor from your unit’s sensor list, as shown below. This example picture shows a Sensor Status Light added to a Rack Map.

  • Page 36: Access Control Users And Groups

    Access Control Users and Groups The Access Control Users and Groups are managed from the AKCPro Server and are used for accessing doors with the Swing Handle Lock. You can only view the existing users and groups from the unit’s Web UI and modify only a few parameters on them. - 36 -...
  • Page 37 This feature has its own manual, refer to the SP+ Swing Handle Lock Manual for more information. - 37 -...
  • Page 38 Notifications and Events You can view all of the SP+ unit’s events and filter them by each of the categories’ listed above in the Events drop down menu. Please refer to the SP+ units “Notifications Manual” for setting up the alerts and the Event log on the units.

  • Page 39: System Page

    System page General Here you can change general settings for the device. The unit’s firmware version is shown in the Description field, and the System Name/Location/Contact options are user configurable. You could also specify the System URL option, for quick access of a custom part of the Web UI for example, but you can specify any URL.
  • Page 40 - 40 -...
  • Page 41 With the option Sensor Notification On System Boot Up, you can choose to allow/disallow running the notifications with sensor values read at system boot up. In some cases, invalid values are read while the unit is starting up, and you could get false alarm notifications. You can enable/disable the notification processing at startup with this option.

  • Page 42: Language Management

    Language management You can change the display language of the Web UI with this option. Only one additional language is supported, together with the default (and fallback if there’s an error) English. In Manage, you can choose to Download Language File if you’d like to edit the language file offline (you can also download the custom language’s file if it’s already present).
  • Page 43 - 43 -...
  • Page 44 You can get separately downloadable language files from our website in the Support section. If you have active internet connection, the unit supports installing the official language files directly from our server. Select a language from the drop-down menu Install New Language: Then press the Install button.
  • Page 45 The unit will notify you about the successful language installation. If you installed it from the list, it won’t change the language of the Web UI automatically. Now you can switch display languages by selecting from the drop-down list on the General page, then pressing Save: After you’ve added the custom language, you can manage it from the same menu: Note: The official language files are also included in the firmware update packages.
  • Page 46 You can also edit the chosen language directly in the Web UI, if you choose Edit Language: - 46 -...

  • Page 47: Date/Time

    Date/Time The system date and time with time zone is user configurable, with NTP server synchronization. If the unit is connected to APS (AKCPro Server), then it will sync with the APS NTP service. Also displayed is the status of the RTC battery (good/bad). F7 units will also let you specify secondary NTP, and secured NTP servers.

  • Page 48: Network

    Network The unit’s MAC ID is displayed here, and all user configurable options for IPv4 with fixed IP or DHCP client mode. F7 units also have IPv6 settings (separately licensed feature), we have a separate manual about this feature. - 48 -...

  • Page 49: Vpn

    This feature requires a separate license. You can read more details about the licensing later in this manual. This feature is used by connecting the SP1+ with the APS VPN server. After the license has been activated and the APS VPN server is set up, you’ll need to fill out the same options here to be able to use the VPN connection (see below).

  • Page 50: Set Up Vpn Connection To Aps (Akcpro Server)

    Set up VPN connection to APS In the following pages, we’ll describe how to set up the VPN connection to APS. 1. On APS HTML, Go to Settings>Server Settings>Virtual Private Network Enable the VPN Server by clicking on the checkbox, and then change the Network Password in Authentication Setting.
  • Page 51 You could also configure the VPN settings using the deprecated APS Windows Client interface: Settings>Server Option>Virtual Private Network - 51 -...
  • Page 52 2. On the SP+ Web UI, enable the VPN First change the VPN Client on the top to "Enabled" and configure the VPN Settings on the form: - Specify the AKCPro Server's IP or DNS name in VPN Server Address - Use the VPN Network Password that you have specified on APS - Set up the the VPN Encrypt Method on the Encryption tab;...
  • Page 53 3. On your APS console, the SP+ unit will be added to the Server Explorer automatically, with an IP address automatically assigned from the range you specified. Important notes: A) If the SP+ was previously added to the APS using a LAN IP, it has to be removed (delete host).

  • Page 54: Smtp (Setup For Gmail & Office365)

    SMTP The SMTP server configuration options are shown here, it’s required to be set up for the Email actions. Fill out all parameters; the address in the Email From parameter will be used by the Email actions by default, but you could change it if your mail server supports it (when it’s not required to match the SMTP user for example).
  • Page 55 - 55 -...
  • Page 56 Settings for Gmail You can use Gmail account to send Email alerts with the settings shown on this screenshot on the left. Important: before this can work, you’ll need to set up an additional setting in your Google account. Open Gmail in a web browser and go to Settings / Accounts and Import / Other Google Account settings Then from the Account...
  • Page 57 Settings for office365 Important Note: Sending office365 email alerts are only supported on the SP+ F7 & H7 units running the latest firmware on our website and are not supported on the older F4 type SP+ units. First you need to ensure that the SMTP settings and the email action configuration are correct as follows (our account is used as an example): - 57 -...
  • Page 58 The mail servers are strict about the "mail from" parameter for antispam methods, and it cannot be different than the email login setting. Please also check our SP+ Knowledge Base using this link: https://www.akcp.com/knowledge-base/sensorprobe-plus-series-knowledge-base/ And also, our SP+ Email Setup Quick Start guide using this link: http://www.akcp.in.th/downloads/Manuals/SP1+/SP+%20Email%20Alerts%20Quick%20Start%20Gui de.pdf...
  • Page 59 SNMP The SNMP service configuration options are shown here, it is required for SNMP operations. SNMPv1 is enabled by default, with community password “public”. This is provided for the easiest integration with third party SNMP tools. For enhanced security, it is recommended that you change the default SNMP password. Scroll down for SNMPv3 options.
  • Page 60 SNMPv3 The SNMPv3 options can be found by scrolling down on the SNMP page. This feature requires a separate license. You can read more details about the licensing below in this manual. Below we’ll give a quick description of each setting: Level Authentication Encryption Description...
  • Page 61 Server Integration If the unit has been added to the AKCPro Server console, the server’s IP address will be displayed here. User configurable options are the APS port and keep-alive period. You can change the APS port when the server’s port changes, and the keep-alive period (heartbeat sync to APS).
  • Page 62 Services You can close or change the ports used to access the unit’s web interface, disable HTTP and enable HTTPS only, which can also be set to be used as default. On the SP+ family, the HTTPS supports TLS v1.1 and v1.2. The HTTPS cypher suites are not customizable.
  • Page 63 SSL Certificate SSL certificates are generated for DNS host names and not IP addresses. You should set a host name for the SP+ unit in your local DNS server or DHCP server, and then generate the SSL certificate for that host name. Example: spplus.mycompany.org The unit’s DNS host name is “spplus”.
  • Page 64 The .PEM file is the private key + certificate combined. You can copy them to one file using Notepad++ if you have 2 separate files, as shown below (it has to be in Unix Line Format and not Windows): - 64 -...
  • Page 65 If you don’t upload a certificate but enable HTTPS, a built-in certificate will be used. You’ll get a browser warning upon opening the Web UI about an incorrect certificate. This is normal and you should add it as an exception or proceed, depending on your browser: Important: the default, built-in self-signed SSL certificate is only provided for user convenience so that the HTTPS WebUI would work on the units out of the box.
  • Page 66 Note: Modbus queries are slow (up to 3 seconds). This is per Modbus protocol definition, it’s not an AKCP limitation. The more sensors you have, the bigger the polling interval must be. Configuring the Modbus options and more information about this feature is explained in the separate SP+ Modbus manual here;...
  • Page 67 Password Checking and Security You can turn on the password checking for the Web UI to ensure only authenticated users have access to the unit. You can also specify to show all user names on the login page, or keep them confidential.
  • Page 68 Allow change the Web UI language - 68 -...
  • Page 69 Password Security options All user account types (Admin, User, Viewer) have adjustable password expiration and lockdown periods. The password can be up to 15 characters (a-z, A-Z, 0-9 and special characters). The IP address of the remote user’s computer will be logged in the syslog so you can trace back each login session to its origin.
  • Page 70 Lockdown - 70 -...
  • Page 71 The accounts can be set to lock down the account after 3 invalid login attempts, to prevent brute-force hacking attempts. You can specify how long the account will automatically unlock itself. Note that for the Admin user, you can’t select “indefinitely” as this would prevent you from logging in to the Web UI if it has locked itself.
  • Page 72 Password Expiration You can specify password expiration between every 15 and 90 days for all account types. You could also set “none” to disable expiration. You’ll get a notification upon login when the password has expired, and will be asked to change it. It’s advised to change it when asked, but you can still proceed without changing.
  • Page 73 Maintenance On this page the following options are available: Clear Event Logs: clears all logged events. Restore Original Settings: removes all customized settings and returns the unit to factory defaults - you can also choose to keep the network configuration intact. Backup/Restore All Settings: the unit’s configuration can be backed up to a file and restored quickly and easily.
  • Page 74 System Firmware Upgrade: allows you to upgrade to the latest firmware of the unit - alternatively you could upgrade from APS. We’ll show you the process of the Web UI firmware upgrade below in another section. System Reboot: this will initiate a software reboot of the unit, useful when you only have remote access.
  • Page 75 Heartbeat Messages This feature allows you to set up periodical “keep alive” notifications task by email, SMS or SNMP Trap to indicate the unit is still working properly. We’ll show you how to set up these in another manual with the other notifications and actions. - 75 -...
  • Page 76 License Management Here you can manage the purchased licenses for specific features on the unit. For example you can request SNMPv3 license by clicking on the Request License button. This will send an email to our Sales team with your unit’s MAC ID. You can then add the purchased license key with the Add button and activate this feature on the unit.
  • Page 77 Features that needs separate licensing: • 5 Dry Contact option: Allows you to connect 5 dry contacts (input only) per sensor ports. See below for more information. • Access Control User licenses over 100: The first 100 user licenses are free (1 is always used for the Admin user), and you can get more licensed users in blocks of 100;...
  • Page 78 About This page shows information about the Manufacturing Date, Ethernet MAC ID, System Description and unit type (F4/F7) which are important when you request support. You could make a similar screenshot when you need help with your unit, as this information can help us diagnose the problem.
  • Page 79 Sensors page On this page you can view all sensors connected to the unit per port. Non-connected sensors will be also displayed, until you re-attach or manually remove them from the configuration. You could also rename the unit’s Main board by clicking on the pencil icon: Please note the maximum supported cable length to use with Thermal Map Sensors: Maximum extension cable length from the SP1+ sensor port to the TMS using CAT5 = 28 Feet Maximum extension cable length from the SP1+ sensor port to the TMS using CAT5e &...
  • Page 80 Important note: If you're using analog pins on the sensor ports (with manually on-lined DCV sensors, and pin 7 of the RJ45 connector) make sure that the voltage doesn't exceed 3 Volts. Otherwise you can damage the unit! - 80 -...
  • Page 81 General options for all sensors You can change the following general options for all sensors: Disable Auto Sense Click on the Auto Sense button to turn off the automatic sensor detection for a port. This feature is useful if you want to simulate a sensor (this works for Relay type sensors) or to prevent a sensor from going offline state.
  • Page 82 You can pre-configure a specific sensor type if needed, for example if you put the sensor offline before. - 82 -...
  • Page 83 Offline a sensor You can manually offline any sensor by clicking on the green Online button on the sensor’s configuration page. You’ll be asked for confirmation in a popup window. Note: if you change a sensor to “offline” it will no longer be displayed on the web interface. In order to reactivate it, you have to toggle it back to “online”.
  • Page 84 Note: If there's a difference between the version stored in the unit's firmware and the sensor’s firmware, it will upgrade/downgrade the sensor’s firmware upon powering up/reboot of the unit, or on sensor reconnection. If you need to downgrade the smart sensor firmware, you can only do so together with the unit’s firmware.
  • Page 85 Change Continuous Time The following advanced functions are for setting the time frame in which the system should delay a notification being triggered when a sensor gives a reading that exceeds the thresholds (high warning, normal, etc). Continuous Time to Report High Critical: This helps to eliminate unnecessary messages during minor fluctuations.
  • Page 86 Virtual Sensors On this page you can configure the Virtual Sensors. The first 5 sensors are free; if you need to use more you can purchase additional licenses (see the Licensing section in this manual). Virtual Sensors can be a very powerful tool in your monitoring system. On the SP1+ you can have up to 32 of these virtual sensors and they allow for a multitude of applications.
  • Page 87 SNMP Get, sensor logic evaluation and ping commands among others are all possible from the virtual sensors. An example use of this could be to use the SP1+ as a probe manager. If you had a SP1+ and multiple sensorProbe devices they could all be monitored, mapped and alerted via the SP1+.
  • Page 88 Example sensor configuration Below we’ll show the configuration of 2 sensor types: the Temperature/Humidity and a Relay sensor. The configuration of these 2 types of sensors covers most settings that can be configured for other sensor types. Temperature/Humidity Sensor Click on the sensor port where the sensor is connected to open the sensor’s configuration. Note: another way of accessing this page is to click on the sensor from the Summary page.
  • Page 89 - 89 -...
  • Page 90 You can re-configure the thresholds for each sensor state. After changing a threshold value, click “Save”. In the next screen shot you can see that a threshold has been changed to 27 make a new “low warning” state, and along with it the sensor status has changed: Note: the Humidity sensor has the same configuration options as the Temperature sensor.
  • Page 91 Advanced sensor configuration for Temperature/Humidity sensors Units: changes units from °C to °F or vice versa. Rearm: The Rearm parameter is useful for sensors whose values can vary such as the temperature and humidity sensors. It is used to prevent the sensor from rapidly changing between two states. For example if the Warning High threshold for the temperature sensor is set to 80 degrees and the sensor were to vary between 79 and 80 you could be faced with a very large number of emails, traps, and events logged.
  • Page 92 Data Collection Type: This refers to the data collection from the sensor and how the data is then displayed on the graphs. There are four options for the collection of data: Average, Highest, Lowest and Instantaneous. The default setting is “Average”. When the data collection type is set to “Average”...
  • Page 93 Relay Sensor Click on the sensor port where the sensor is connected to open the sensor’s configuration. Note: another way of accessing this page is to click on the sensor from the Summary page. You can directly see the Relay’s current status below the sensor port. Boot Up State: You can change the state of the relay when the unit starts.
  • Page 94 Color: You could assign a custom color for the Off/On status: click on the color and the color picker will be shown. - 94 -...
  • Page 95 Advanced sensor configuration for Relay sensors Sensor Control: This button allows you to manually control the relay by controlling the cycle of the relay in an on-off- on or an off-on-off cycle. You can also set the “Toggle” (Cycle Time) here in seconds. You don’t need to change an option to be able to link the relay to an action.
  • Page 96 Enable Calendar: Allows you to setup a Calendar Profile for what days and times you want or do not want the relay to be active. Click on the Edit button next to a selected calendar to modify it. Blue cells means that the notification is on, white cells means it’s off. - 96 -...
  • Page 97 You can quickly select the Working Hours only, and specify a custom schedule down to minutes by right clicking on a cell. - 97 -...
  • Page 98 Pulse Counter sensor The pulse counter is available on the SP+ platform, as of firmware version 1.0.4967. It provides: - accumulated pulse count - flow conversion of the pulse count It can measure up to 1000 pulses / sec (1 Kilohertz). Normally this sensor should be used with some external sensor which outputs pulses.
  • Page 99 For example, you can connect the output of a third-party water flow sensor in the market to our sensor port. The specs of those sensors will indicate how many pulses equal to, for example 1 liter: 100 pulses = 1 Liter. Then you can set the "Number of Pulses per Unit"...
  • Page 100 In the Flow Sensor there is "Number of Pulse per Unit" in the config. You can use this value to adjust the sensor reading to match the real-world value. Dry contact will also work but only to count the pulses. If you want to test for the rate accuracy, you'd have to test with something that can generate a wave signal, like using an oscilloscope to generate wave form and plug it to the sensor port.
  • Page 101 Firmware upgrade through the Web UI The firmware upgrade process is very simple and straight-forward. Open the System/Maintenance page and click on the Upgrade button at the System Firmware Upgrade section. This will load the Upgrade page. Choose the firmware file from your PC and click on Upgrade to start the process.
  • Page 102 - 102 -...
  • Page 103 First the file will be uploaded to the unit… …then the upgrade process will run. The whole process can be done in a few minutes. The Power/Ethernet LED will be red during the upgrade. The unit will reboot at the end of the upgrade. Click on the Refresh button to reload the Web UI. - 103 -...
  • Page 104 Network ports used by SP+ units Below we list the ports used by our SP+ units. Most of them are needed for external communications with APS, and to use network features. Most ports are user configurable, these are the default ports. Main ports: ▪...
  • Page 105 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 106 Please contact support@akcp.com if you have any further technical questions or problems Thanks for Choosing AKCP! - 106 -...
