Summary of Contents for ACME Energy Spot PRO

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ..................2 2. Technical Specifications ................. 4 3. Control Panel ....................6 4. Color/Gobo ....................7 5. How To Set The Unit ..................7 5.1 Main Function ..................7 5.2 Home Position Adjustment ..............14 6. Control By Universal DMX Controller ............18 6.1 DMX512 Connection ................

  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
  • Page 4 off the mains power immediately. DO NOT operate in dirty or dusty environment, do clean fixtures regularly.  DO NOT touch any wire during operation as there might be a hazard of electric shock.  Avoid power wires together twist other cables. ...

  • Page 5: Technical Specifications

    2. Technical Specifications Power Voltage: AC 100~240V, 50/60Hz Power Consumption: 450W Light Source: HL-270-B Color Temperature: 8000K Zoom Range: 8°~45° Movement: Pan: 540° Tilt: 270° Pan/Tilt Resolution: 16 bit Fixation: Tilt lock Color Wheel: 1 color wheel with 9 colors plus white Gobo Wheel: 1 static gobo wheel with 9 gobos plus open 1 rotating gobo wheel with 7 gobos plus open, convenient replacement...
  • Page 6 Protection Rating: IP20 Features: Motorized focus Linear CMY color mixing Motorized linear iris 3 x facets prism rotating in both directions Independent frost effect Various strobe speeds Dimension/Weight: 369x253x625mm, 20.8kgs 14.5"x9.9"x24.6"in, 45.9lbs...

  • Page 7: Control Panel

    3. Control Panel 1. LED: POWER Power On DMX input present 2. Button: MENU To enter into move backward or leave the menu To go backward in the selected functions DOWN To go forward in the selected functions ENTER To confirm the selected functions 3.

  • Page 8: Color/Gobo

    4. Color/Gobo DANGER! Install the color wheel/gobo wheels with the device switched off only. Unplug from mains before changing the color wheel/gobo wheels! CAUTION: Never unscrew the screws of the rotating gobo as the ball bearing will otherwise be opened! 5.
  • Page 10 DMX Functions To select DMX Functions, press the ENTER button to confirm, use the UP/DOWN button to select DMX Address, DMX Channel Mode, DMX State or View DMX Value. DMX Address To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the address from 001 to 495/491/488, press the ENTER button to store.
  • Page 11 Tilt Invert To select Tilt Invert, press the ENTER button to confirm. Use the UP/DOWN button to select No(normal) or Yes(tilt invert), press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle 30 seconds to exit menu mode. P/T Feedback To select P/T Feedback, press the ENTER button to confirm.
  • Page 12 Focus Compensate To select Focus Compensate, press the ENTER button to confirm. Use the DOWN/UP button to select Disable, Near, Medium or Far, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle 30 seconds to exit menu mode. Display Setting To select Display Setting, press the ENTER button to confirm, use the UP/DOWN button to select Display Invert, Backlight Intensity, Temperature Unit or Language.
  • Page 13 Fixture Test To select Fixture Test, press the ENTER button to confirm, use the UP/DOWN button to select Auto Test or Manual Test. Auto Test Select Auto Test, press the ENTER button to confirm, the unit will run built-in programs to automatically test pan, tilt, color, gobo, gobo rotation, prism, prism rotation, iris, frost, focus, zoom, dimmer, etc.
  • Page 14 Firmware Version Select Firmware Version, press the ENTER button to confirm, firmware version will show on the display, press the MENU button back to exit. RDM UID Select RDM UID, press the ENTER button to confirm, RDM UID will show on the display, press the MENU button back to exit.

  • Page 15: Home Position Adjustment

    Special Functions Factory Setting Select Factory Setting, press the ENTER button to confirm, use the UP/DOWN button to select No(normal) or Yes(the fixture will reset to factory settings), press ENTER button to store. Press the MENU button to exit. RDM FUNCTIONS Select the MANUFACTURER menu to display the manufacturer of the fixture.
  • Page 16 Enter offset menu, select Pan, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Tilt Enter offset menu, select Tilt, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER...
  • Page 17 Magenta Enter offset menu, select Magenta, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Yellow Enter offset menu, select Yellow, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the...
  • Page 18 R-Prism 1 Enter offset menu, select R-Prism 1, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Iris Enter offset menu, select Iris, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER...

  • Page 19: Control By Universal Dmx Controller

    6. Control By Universal DMX Controller 6.1 DMX512 Connection DMX Out 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.

  • Page 20: Address Setting

    6.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button to enter menu mode, select DMX Settings, press the ENTER button to confirm, use the UP/DOWN button to select DMX Address, press the ENTER button to confirm, the present address will blinking the display, use the UP/DOWN button to adjust the address from 001 to 512, press the ENTER button to store.
  • Page 21 025-064 Strobe 1: fast to slow 065-069 Open 070-084 Strobe 2: opening pulse, fast to slow 085-089 Open 090-104 Strobe 3: closing pulse, fast to slow 105-109 Open 110-124 Strobe 4: random strobe, fast to slow 125-129 Open 130-144 Strobe 5: random opening pulse, fast to slow 145-149 Open 150-164...
  • Page 22 Gobo1 000-007 Open 008-015 Gobo1 016-023 Gobo2 024-031 Gobo3 032-039 Gobo4 040-047 Gobo5 048-055 Gobo6 056-063 Gobo7 064-072 Gobo1 Shaking 073-081 Gobo2 Shaking 082-090 Gobo3 Shaking 091-099 Gobo4 Shaking 100-108 Gobo5 Shaking 109-117 Gobo6 Shaking 118-127 Gobo7 Shaking 128-190 Rotation, Fast to Slow 191-192 Stop 193-255...
  • Page 23 128-190 Rotation, Fast to Slow 191-192 Stop 193-255 Rotation, Slow to Fast Iris 000-255 100%0% Prism 000-010 No Effect 011-127 Prism On 128-255 Prism Macro1 to Macro32 R-Prism 000-127 Index 0°360° 128-190 Rotation, Fast to Slow 191-192 Stop 193-255 Rotation, Slow to Fast Frost 000-255 0%100%...
  • Page 24 22 Channels Mode (Mode 2): Channel Value Function Cyan 000-255 0%100% Magenta 000-255 0%100% Yellow 000-255 0%100% Color 000-006 Open 007-012 Color1 013-018 Color2 019-025 Color3 026-031 Color4 032-037 Color5 038-044 Color6 045-050 Color7 051-056 Color8 057-063 Color9 064-127 Color Index 128-190 Rotation, Fast to Slow 191-192...
  • Page 25 210-224 Strobe 9: sine wave, fast to slow 225-229 Open 230-244 Strobe 10: burst, fast to slow 245-255 Open Dimmer 000-255 0%100% 000-255 Dimmer Fine Gobo1 000-007 Open 008-015 Gobo1 016-023 Gobo2 024-031 Gobo3 032-039 Gobo4 040-047 Gobo5 048-055 Gobo6 056-063 Gobo7 064-072...
  • Page 26 071-077 Gobo2 Shaking 078-084 Gobo3 Shaking 085-091 Gobo4 Shaking 092-098 Gobo5 Shaking 099-105 Gobo6 Shaking 106-112 Gobo7 Shaking 113-119 Gobo8 Shaking 120-127 Gobo9 Shaking 128-190 Rotation, Fast to Slow 191-192 Stop 193-255 Rotation, Slow to Fast Prism 000-010 No Effect 011-127 Prism On 128-255...
  • Page 27 110-119 BlackOut Gobo Move Enable 120-129 BlackOut Gobo Move Disable 130-139 Focus Compensate Disable 140-149 Focus Compensate Near 150-159 Focus Compensate Medium 160-169 Focus Compensate Far 170-199 Null 200-209 Reset All 210-219 Reset Effect 220-229 Reset Pan/Tilt 230-255 Null 25 Channels Mode (Mode 3): Channel Value Function...
  • Page 28 Color 000-006 Open 007-012 Color1 013-018 Color2 019-025 Color3 026-031 Color4 032-037 Color5 038-044 Color6 045-050 Color7 051-056 Color8 057-063 Color9 064-127 Color Index 128-190 Rotation, Fast to Slow 191-192 Stop 193-255 Rotation, Slow to Fast Cyan 000-255 0%100% Magenta 000-255 0%100% Yellow...
  • Page 29 000-127 Index 0°360° 128-190 Rotation, Fast to Slow 191-192 Stop 193-255 Rotation, Slow to Fast Gobo2 000-006 Open 007-012 Gobo1 013-018 Gobo2 019-025 Gobo3 026-031 Gobo4 032-037 Gobo5 038-044 Gobo6 045-050 Gobo7 051-056 Gobo8 057-063 Gobo9 064-070 Gobo1 Shaking 071-077 Gobo2 Shaking 078-084 Gobo3 Shaking...
  • Page 30 000-255 100%0% Shutter 000-019 Blackout 020-024 Open 025-064 Strobe 1: fast to slow 065-069 Open 070-084 Strobe 2: opening pulse, fast to slow 085-089 Open 090-104 Strobe 3: closing pulse, fast to slow 105-109 Open 110-124 Strobe 4: random strobe, fast to slow 125-129 Open 130-144...

  • Page 31: Error Information

    7. Error Information 1. Pan Reset Error Check if the position of the pan mounting magnetic steel falls off or is damaged. Check if there are other interference items in the pan operating range. Check if the pan Hall elements is damaged. Check if the pan Hall elements is in poor contact with the lead of the PCB board or disconnected.
  • Page 32 Check if the color wheel Hall elements is in poor contact with the lead of the PCB board or disconnected. Check if the color wheel motor is damaged. Check if there is any damage to the circuit of the color wheel motor drive board. 7.
  • Page 33 10. Gobo1/2 Reset Error Check if the position of the gobo wheel1/2 mounting magnetic steel falls off or is damaged. Check if there are other interference items in the gobo wheel1/2 operating range. Check if the gobo wheel1/2 Hall elements is damaged. Check if the gobo wheel1/2 Hall elements is in poor contact with the lead of the PCB board or disconnected.

  • Page 34: Troubleshooting

    Check if there is any damage to the circuit of the focus motor drive board. 14. Zoom Reset Error Check if the position of the zoom mounting magnetic steel falls off or is damaged. Check if there are other interference items in the zoom operating range. Check if the zoom Hall elements is damaged.

  • Page 35: Fixture Cleaning

    9. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
  • Page 36 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU. EN 55032: 2015; EN 61000-3-2: 2014; EN 61000-3-3: 2013; EN 55103-2: 2009. &...
