M2Tech
YOUNG M
IV
K
DIGITAL-TO-ANALOG CONVERTER AND PREAMPLIFIER
www.m2tech.biz
REVISION PrA – DECEMBER 2020
®
14) Bluetooth
module receiver antenna. Keep this antenna clear from metal shields or
covers.
15) I2S connector. Connect to the PS Audio compliant I2S output of a streamer, digital
disc player or other I2S digital source using a standard HDMI cable. Female HDMI
connector.
16) USB connector. Connect to the USB 2.0 port of a computer using the stock USB
cable. Type "B" female USB connector.
17) Trigger output. Connect to the trigger input of any other device accepting 12V
.
DC
Female 3.5mm jack.
18) Power supply input. Connect the connector from the stock 15V-1.2A adaptor or from
the Van Der Graaf MkII. 5.5/2.1mm jack with positive on tip.
Copyright © 2017, M2Tech Srl
13
