Installation Instructions
Model Number VRB46
Zero Clearance Vented Gas Fireplace Heater
Stock #'s: VRB46N, VRB46NE, VRB46LP, VRB46LPE
Conforms to: ANSI Z21.88-2016 • CSA 2.33-2016
VENTED GAS FIREPLACE HEATER
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This Appliance Is Only Approved With
Kingsman Flex Vent System, Except When
Using The Power Venting Option.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada February 16, 2018 Part # 46VRB-MAN16
