Kingsman ZCV39N Installation Instructions Manual

Zero clearance vented gas fireplace heater
Hide thumbs Also See for ZCV39N:
Table of Contents

Advertisement

Quick Links

Model Numbers:
Certified to:
Model Numbers:
Certified to:
This appliance may be installed in an aftermarket, permanently located, manufactured home (USA
only) or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
-WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department
-Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
⚠WARNING
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed.

Installation Instructions

ZCV39N, ZCV39NE, ZCV39LP, ZCV39LPE
ZCV42N, ZCV42NE, ZCV42LP, ZCV42LPE
ANSI Z21.50-2012, CSA 2.22-2012, CGA 2.17-M91
ZERO CLEARANCE VENTED GAS FIREPLACE
ZCV39NH, ZCV39NHE, ZCV39LPH, ZCV39LPHE
ZCV42NH, ZCV42NHE, ZCV42LPH, ZCV42LPHE
ANSI Z21.88a-2012, CSA 2.33a-2012, CGA 2.17-M91
ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
HOT GLASS WILL
CAUSE BURNS
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
BENTLEY
For Propane Horizontal
installations the venting must
be an additional one foot
above the minimum vertical
rise off the flue before going
horizontal.
A Division of R-Co. Inc.
2340 Logan Ave.
Winnipeg, Manitoba Canada
R2R 2V3 Ph.: (204) 632-1962
Printed in Canada March 3, 2014
Part# 39ZCV-MAN
