VENTED & VENT-FREE GAS LOG
Owner' s Operation and Installation Manual
GLMVF38MVN, GLMVF38MVP, GLMVF40MVN, GLMVF40MVP
Vented:
Certified for USA and Canada: ANSI Z21.60/2003, ANSI Z21.60a/2003, ANSI Z21.60b/2004,
If the information in this manual is not followed exactly, a fire or
explosion my result causing property damage, personal injury, or
loss of life.
– Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
– Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room
in which it is installed. Provisions for adequate combustion and ventila-
tion air must be provided. Refer to "Air for Combustion and
Ventilation" section of this manual, page 7.)
• 2340 Logan Ave., Winnipeg, MB, Canada, Phone: (204) 632-1962 • Printed in Canada • July 27, 2009 • PART #38GL-MAN
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Listed Certified for USA and CANADA
Vent-free:
Certified to USA standards: ANSI Z21.11.2 - 2007
CSA 2.26/2004, CSA 2.26a/2003,CSA 2.26b/2004
This appliance must be installed by a licensed plumber or gas
fitter in the Commonwealth of Massachusetts and meet the
Warning
Warning
requirements of 527 CMR 30 and 248 CMR.
Improper installation, adjustment,
alteration, service, or maintenance can
cause injury or property damage. Refer
to this manual for correct installation and
operational procedures. For assistance or
additional information consult a qualified
installer, service agency, or the gas supplier.
These gas logs sets are for installation in
a masonry solid fuel burning fireplace,
a U.L. listed manufactured solid fuel
burning fireplace. The vent free gas log
sets are also AGA design, certified for
vent free Universal Fireboxes.
Minimum Fireplace Dimensions:
1
Warning
Warning
see page 11
