6.12 Remote Clutch and Remote Throttle Assembly

20
14
15
17
16
18
13
11
ITEM # PART NO.
STD.6550B
1 STD.6551A
2 STD.6551A.01 Thick Spacer
3 STD.6551A.02 Thin Spacer
4 STD.2919
5 STD.6554
STD.6554B
6 STD.6556
7 STD.6559
8 STD.6553
STD.6553B
9 STD.6557
10 STD.6558
ODB COMPANY
19
20
21
DESCRIPTION
Entire Assembly
Mounting Base
CPC Plug, 6 Pin
Clutch Cable - Direct Drive
Clutch Cable - Belt Drive
Clutch Actuator (top)
Cable Adaptor - clutch
Throttle Cable - direct drive
Throttle Cable - belt drive
Throttle Acutator (bottom)
Cable Adaptor-throttle
after March 2002- ver. 2
22
1
12
7
10
6
ITEM #
11
12
13
14
15
16
17
18
19
20
21
22
23
800-446-9823
4
23
8
9
PART NO. DESCRIPTION
STD.6552A Cover
4045.6565 Throttle Cable Bracket
4045.6564 Clutch Cable Bracket
STD.6563 Torque Coupling
STD.6562 Coupling Sleeve
STD.6560 PTO Cable Adaptor
STD.6561 Roller Bearing
STD.6568 Spacer Washer
STD.6569 Collar Cam (3x only)
800.434 Limit Switch (3x only)
STD.6571 Cover
STD.6570 Limit Switch Bracket
STD.2916 CPC Housing
Wires are a part of the Remote
Clutch and Throttle Acuators
3
2
5
83
LCT60C
