Engine Wiring Harness Descriptions, Continued - ODB LCT60C Owner's Manual

FUEL & LIMIT SWITCH HARNESS
Pink
Black
Tan
Black
Tan w/ Black Stripe
Black
[empty]
REMOTE THROTTLE AND CLUTCH HARNESS
1 Yellow
2 Black
3 Yellow w/ Green Stripe
4 Green w/ Yellow Stripe
5 [empty]
6 [empty]
7 Yellow w/ Blue Stripe
8 Blue w/ Yellow Stripe
9 [empty]
AUX PLUG IN HARNESS
1 Yellow
2 Black
3 Yellow
4 Black
5 Yellow
6 Black
7 [empty]
8 Orange w/ Yellow Stripe
9 Yellow w/ Orange Stripe
ODB COMPANY
Service Section

5.10.4 Engine Wiring Harness Descriptions, continued

Fuel Sender "+"; came from Engine Main Harness pin #10
Fuel Sender "-"; came from ground to solenoid
Inspection Door "+"; came from Engine Main Harness pin #9
Inspection Door "-"; came from ground to solenoid
Emergency Stop Button "NO"; came from Engine Main Harness #8
Emergency Stop Button "COM"; came from ground on Solenoid
"+" from Ignition; came from Aux Engine Harness pin# 3
"-" from Ignition; came from ground on Solenoid
Clutch Engage; came from Aux Engine Harness pin# 6
Clutch Disengage; came from Aux Engine Harness pin# 4
Throttle Fast; came from Aux Engine Harness pin# 9
Throttle Slow; came from Aux Engine Harness pin# 11
"+" from Ignition; came from Aux Engine Harness pin# 14
"-" from Ignition; came from ground on Solenoid
"+" from Ignition; came from Aux Engine Harness pin# 16
"-" from Ignition; came from ground on Solenoid
"+" from ignition; came form Aux Engine Harness pin# 2
"-" from ignition; came from ground on solenoid
Rocker Switch; came from Aux Engine Harness pin# 5
Rocker Switch; came from Aux Engine Harness
