ENGINE MAIN HARNESS
PIN # COLOR
1 Red
2 Red w/ Blue Stripe
3 Orange
4 Black
5 Purple
6 White w/ Red Stripe
7 White
8 Tan w/ Black Stripe
9 Tan
10 Pink
11 Blue
12 Blue w/ Black Stripe
13 Red w/ Black Stripe
AUXILLARY ENGINE HARNESS
1 Red 10 Gauge
2 Yellow
3 Yellow
4
5
6 Yellow w/ Green Stripe
7 [empty]
8 Green w/ Yellow Stripe
9 Yellow w/ Blue Stripe
10 [empty]
11 Blue w/ Yellow Stripe
12 Yellow w/ Purple Stripe
13 Purple w/ Yellow Stripe
14 Yellow
15 Black 10 gauge
16 Yellow
STROBE LIGHT HARNESS
Yellow w/ Purple Stripe
Black
Purple w/ Yellow Stripe
Black
ODB COMPANY
Service Section

5.10.4 Engine Wiring Harness Descriptions

DESCRIPTION
"+" from Solenoid (battery)
Starter Solenoid
Fuel Shutoff Solenoid
"-" from Solenoid (battery)
Alternator Energize "+"
Oil Sender
Tach Signal from Alternator
Emergency Stop Button (650 only) goes to Limit Switch plug pin #5
Inspection Door on Blower Housing, goes to Limit Switch plug pin #3
Fuel Sender, goes to Limit Switch Plug pin #5
Water Temperature Sender on Engine Block
Water Temperature Switch on Engine Block
Oil Pressure Switch on Engine Block
"+" from Solenoid (Battery)
Aux "+" from Ignition; goes to Aux Plug Harness pin #5
Aux "+" from Ignition; goes to Remote Clutch Harness pin #5
Clutch Engage; goes to Remote Clutch Harness pin #3
Clutch Disengage; goes to Remote Clutch Harness pin #4
Throttle Fast; goes to Remote Clutch Harness pin #7
Throttle Slow; goes to Remote Clutch Harness pin #8
Strobe Light "+"; goes to Strobe Light Harness pin #1
Strobe Light Aux; goes to Strobe Light Harness pin #3
Aux "+" from Ignition; goes to Aux Plug Harness pin #1
"-" from Solenoid (Battery)
Aux "+" from Ignition; goes to Aux Plug Harness pin #3
Fuel Sender "+"; came from Engine Main Harness pin #10
Strobe Light "-"; came from ground to solenoid
Strobe Switch Aux "+"; came from Aux Engine Harness pin #13
Strobe Switch Aux "-"; came from ground on Solenoid
Continued ... -->
