Sheet Metal Group - ODB LCT60C Owner's Manual

11
17
16
14
ITEM# PART NO.
1 4045T.2102
4045T.2102S
2 4045.2102A
3 4045.2102C
4 LCT60.624A
5 4045.2102B
6 4045.2101
7 4045.0018
8 LCT650.114
9 4045.2109
10 4045.2106A
ODB COMPANY

6.4 Sheet Metal Group

July 2001 and after
3
4
5
9
12
18 18 18 18
13
DESCRIPTION
Hood, not SCL
Hood, SCL800, JD TURBO
Radiator Access Door
Radiator Access Door Hinge
Lift and Turn Latch
Oil Fill Access Door
Front Panel
Radiator Screen
Radiator Screen Clamp
Panel Door, LH
Upper Side Panel, LH
3
4
2
14
6
ITEM# PART NO.
11 4045.2112C
4045.2112T
12 4045.2105A
13 4045.2108
14 LCT60.624
15 LCT609.602
16 4045.2112F
17 STD.6304
18 2856.26012
800-446-9823
1
10
15 15
8 8
7
DESCRIPTION
Rear Panel, NOT SCL
Rear Panel, SCL
Upper Side Panel, RH
Panel Door, RH
Lift and Turn Latch
Overcenter Latch
Cover, Solenoid
Wiring Plug Bracket
Door Grommet
LCT60C
75
