Installation
The Contera
®
Micro Bullet camera can be directly attached onto hard ceilings or walls including wood,
plastic, metal and concrete.
1. Determine a secure location to mount the camera
2. Use the template, anchors, and screws provided to prepare the mounting provisions for the camera
installation.
3. Install three supplied dry wall anchors using the supplied mounting template
4. Connect the network cable to the camera's RJ45 connector
5. Align three supplied screws with the dry wall anchors and the camera into place
6. To configure the camera, reference the camera discovery, set-up and configuration section.
7. Follow below instruction to adjust the Pan/ Tilt and rotate the gimbal for the desired field of view.
NOTE: Do not remove the screws!
Contera Indoor Dome | Installation Manual
7
