Arecont Vision
AV2100, AV3100, AV3130
Camera Installation Guide and Reference
Rev 2.3.1
July 27, 2005
support@arecontvision.com
AV SDK AND ASSOCIATED FILES ARE PROVIDED FOR CUSTOMER CONVENIENCE ON AS-IS
BASIS. ARECONT VISION, LLC DISCLAIMS ALL WARRANTIES WITH REGARD TO THIS
SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS.
IN NO EVENT SHALL ARECONT VISION BE LIABLE FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF
USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER
TORTUOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR
PERFORMANCE OF THIS SOFTWARE.
Advertisement
Table of Contents
Related Manuals for Arecont Vision AV2100
Summary of Contents for Arecont Vision AV2100
- Page 1 BASIS. ARECONT VISION, LLC DISCLAIMS ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL ARECONT VISION BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF...
-
Page 2: Table Of Contents
Connecting Directly To Laptop or PC ....................... 7 Switches and Routers..........................7 Low Sharpness............................8 Regulatory Compliance ..........................8 FCC Compliance Statement........................8 Related Documentation ..........................8 Terms and Conditions of Sale ........................8 Revision History............................10 Arecont Vision Proprietary And Confidential... -
Page 3: Introduction
Installation And Software Manual Introduction Thank you for purchasing AV mega-pixel IP video cameras. AV2100, AV3100 and AV3130 are state-of- the-art IP designed to deliver full motion high definition digital video across local area networks. Delivering over 40 Mpixels/sec of crystal-clear imagery, AV cameras represent a vastly superior alternative to low resolution analog and digital video. -
Page 4: Camera Location And Environment
1 lb camera plus the weight of the lens. Camera Power Supply AV2100 and AV3100 cameras should be powered from 9V to 12V DC power source providing at least 4W per camera. AV3130 requires 5W. 12V – 1A is recommended. Alternatively, the cameras can be powered over Ethernet with 48V. -
Page 5: Camera Reference
AV2100, AV3100 and AV3130 are mega-pixel resolution IP cameras capable of delivering crisp, low- noise images at a video frame rate. AV2100 is a 2-megapixel resolution camera having maximum resolution of 1600 by 1200 and achieving a maximum frame rate of 24. -
Page 6: Housing And Mounting
Optics AV2100 and AV3100 can be used with a manual or DC ½” auto-iris lens. AV3130 requires two manual iris lenses and has a limitation on lenses size. The lens mount can be C or CS with an appropriate adapter. -
Page 7: Day/Night Operation
See “AV Video Software Reference Manual” for details on configuring settings specific to AV3130. Supported Network Services AV2100, AV3100 and AV3130 implements Ping, ARP and TFTP network protocols. Ping Ping protocol checks if the network device is on, available on the network and can successfully receive and transmit network packets. -
Page 8: Low Sharpness
Regulatory Compliance FCC Compliance Statement AV2100 and AV3100 has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 9 Product and shall follow AV’s instructions regarding disposition of the rejected Product. Prior to the return of any Product to AV as provided for hereunder, Purchaser shall obtain from AV’s Technical Support Department a Return Material Authorization (“RMA”) number. Within ten (10) business days after Arecont Vision Proprietary And Confidential...
-
Page 10: Revision History
Purchaser may not assign its rights or delegate its obligations hereunder without the express written consent of AV. Any assignment by Purchaser without such consent shall constitute a breach hereof by Purchaser. Revision History Version 2.3 Manual divided into 3 documents, 2.3.1 • Arecont Vision Proprietary And Confidential p.10...
