Contera Indoor Dome | Installation Manual
Camera Name
Background
Translucent
Transparent
Text Color
Text Overlay
Off
Date/Time
Camera Name
Camera Name +
Date/Time
Custom Text
ROI (Regions of Interest)
Specifies a name for the camera. The maximum length
is 32 characters.
Configures the background color of the text overlay.
The options are Translucent (light grey) or Transparent.
Options are Black, White, Green, or Yellow.
There are four content positions
Bottom Left and Bottom Right) to display the text
overlay.
Date/ Time: Displays the current date/time. It will force
the camera to synchronize the date/time information.
Camera Name: Displays the camera name you set.
Camera Name + Date/Time: Displays both camera
name and date/time information.
Custom Text: Displays a customized text.
ROI (Regions of Interest) is used to select which areas
will be monitored and recorded with higher image
quality while using lower image quality for other non-
ROI zones to save bandwidth and storage.
To setup the ROI:
1. Select Main Stream or Sub Stream
2. Enable zones (up to five zones) and select the
desired quality level (High, Medium, or
3. Create the ROI by dragging the mouse over the
live image
4. Press Save Area or Del Area.
(Top Left, Top Right,
Low).
