Bottom View

9
8
# Feature
1 Dual External Antenna
Connector (DEAC)
2 CRMA Express Module
3 Memory compartment
4 WLAN compartment
5 Speakers
6 Hard Disk Drive Locks
7 Docking Connector
8 Media Bay Release
9 Media Bay Lock Slide
10 Battery Pack
General Dynamics Itronix 72-0146-001
10
7
6
Description
The DEAC gives you the ability to switch the internal WLAN and WWAN to an external
antenna to gain better performance when you are in a vehicle.
Upgradeable WWAN radio module (optional)
User expandable memory slot
Integrated wireless LAN radio
Integrated stereo speakers for audio output
Open and turn these to lock or unlock the removable hard disk drive
84-pin cradle connector that mates with the Vehicle Dock, or Office Dock
After unlocking the media drive, slide this to release the media drive.
Slide to unlock the media drive before releasing it
Smart Lithium-Ion battery
Getting Familiar With Your Computer
