GD6000 User Guide

Bottom View

# Feature
1 Docking Connector
2 Memory compartment
3 Hard Disk Lock
4 Hard Disk Drive
5 Battery Locks
6 Battery
7 Battery Release Latch
General Dynamics Itronix | 72-0136-005
Getting Familiar With Your Computer
Description
84-pin cradle connector that mates with the
User expandable memory slot.
Slide this to lock or unlock the hard disk drive.
Removable hard disk drive for data storage.
Slide these locks toward the outer edges of the computer to lock the battery.
Lithium-Ion Smart Battery.
Slide this latch to the left to remove the battery.
the battery.
Vehicle Dock and office Dock.
note
You must first unlock
