GD8200 User Guide
NOTE
All WWAN radios are capable of backward
compatibility to support slower technologies when necessary
to provide the greatest possible coverage to the user.

EVDO Rev. A

EVDO Revision A (1x Evolution-Data Optimized) is a wireless
radio broadband data standard that offers download
speeds up to 3.1 Mbps (500 to 800 Kbps typical). Revision A
integrates faster data technology and improves latency. These
enhancements allow features such a VoIP and video calling.
EV-DO Rev. 0
Evolution Data Only or Evolution Data Optimized (EV-DO) Rev
0 is a 3G wireless technology with average user download
speeds up to 2.4 Mbps (400-700 kbps typical). When you spend
a lot of time away from your desk, the faster speeds from
EV-DO can lead to greater productivity. It's more than just fast
email retrieval. Get fast and secure access to your information
and applications with EV-DO. EV-DO Rev 0 was upgraded to
EV-DO Rev A.
1XRTT - Single Carrier (1x) Radio Transmission Technology
1xRTT is a pre-2G wireless technology based on the CDMA
platform. It has the capability to provide ISDN like speeds that
offer up to 144 Kbps (50-70 Kbps typical). 1xRTT is also referred
to as CDMA2000. 1xRTT was upgraded to EV-DO.

GPS (option)

The Global Positioning System (GPS) is a worldwide radio-
navigation system formed from a constellation of satellites and
their ground stations. GPS uses these satellites as reference
points to calculate positions accurate within five meters.
Bluetooth (option)
®
Bluetooth is a short range, wireless technology. Bluetooth
®
systems create a Wireless personal-area network (WPAN).
When Bluetooth -capable devices come within range of one
®
another, an electronic conversation automatically takes place
to determine whether they have data to share or whether one
needs to control the other. Then, the devices hop frequencies
in unison so they stay in touch with one another and avoid
interference with other devices.
Bluetooth devices send out weak signals of 1 milliwatt. Class
®
II Bluetooth devices have a range of about ten meters while
®
Class I devices have a range up to 100 meters. The GD8200
Bluetooth option is a Class I device with the greater range.
®
Even with the low power, the walls in your house won't stop
a Bluetooth signal. This makes the standard useful for
®
controlling several devices in different rooms. However,
obstructions such as walls do degrade the signal and reduce its
range.
General Dynamics Itronix 72-0146-001
Wireless Communication

Antennas

The GD8200 has several embedded antenna options to support
wireless communications. They require no user action.
CAUTION
Use only the supplied or an approved antenna(s).
Use of unauthorized antennas, modifications, or attachments
may void your warranty and could impair call quality, damage
the radio, or result in violation of FCC regulations.
The GD8200 may contain the radio transmitters listed below.
The following statements are relevant when using these radios:
This device may contain a WLAN radio transmitter, a WPAN
radio transmitter, and a WAN radio transmitter.
Each internal radio may or may not have an individual FCC
Identifier label. That FCC Identifier label is not applicable to this
configuration. Only the external FCC ID label is applicable.
Only the antenna with which an intentional radiator is
authorized may be used with the intentional radiator.
The WAN embedded antenna location is in the upper center
edge of the display screen and is not to be modified.
The WPAN embedded antenna location is near the lower left
edge of the Keyboard and is not to be modified.
The WLAN embedded dual antennas are located internally in
the upper right and left edges of the display screen and are not
to be modified.
To comply with FCC RF exposure requirements when using the
WAN radio transmitter, a minimum separation distance of 20
cm must be maintained between the upper center edge of the
display screen antenna and all users/bystanders.
When using the WLAN transmitter, a minimum separation
distance of 20 cm must be maintained between the upper right
and left edges of the display screen and all users/bystanders.
The WAN transmitter, WLAN transmitter and WPAN
®
transmitter should be turned off before carrying the Laptop PC
in order to comply with FCC RF exposure requirements.
Since each customer's radio configuration is unique, please
read the radio help installed on your desktop and refer to the
manufacturer documentation to setup and use your radio(s).

Improving Radio Coverage

Radio connectivity between your computer and your wireless
network may vary at different times of the day and in different
types of weather. It may also be influence by terrain, buildings
or even a crowded room. Follow these tips to improve radio
coverage between your computer and your wireless network,
depending on your location.
