GD8200 User Guide
Audio
Your computer includes 24-bit high-fidelity stereo audio
output and an integrated microphone. You can also attach
external audio devices via the audio in and out jacks on the
left side of the computer.
Adjust the Volume
To decrease volume, press
„
To increase volume, press
„
To mute the volume, press
„
You can also adjust the volume with the Windows
control applet located on the taskbar. However, the volume
control function keys override the Windows
applet. If your volume is too low or too high after setting the
volume in the applet, adjust the volume with the function
keys.
The PC Card Slot
Use the PC card slot, located on the right side of the computer under the media bay, as an interface between your computer and
a variety of communications devices, such as network adapters, SCSI adapters, and fax/modems, or to provide additional data
storage capacity. Your computer's PC Card slot supports single Type I or II PC Cards, 32-bit CardBus cards, and Zoomed Video
cards.
CAUTION
Do not remove or change any hardware while your computer is hibernating or in a Sleep/Standby state.
Inserting the Card
1.
The top side of a PC Card is usually identified with a label.
Insert the card into the slot with the top up and the edge with
pinhole contacts or arrow, going in first. You will feel some
resistance as the card slides into the back of the slot.
2.
PC Cards require drivers, or a program that allows the operat-
ing system to use a specific device. Many drivers are included
with Windows
®
so the PC Card will be automatically recognized;
but if not, you will be prompted to install the driver included
with your card.
3.
The PC Card becomes a removable disk drive and is assigned a
letter drive.
NOTE
Please read the instructions included with individual
PC Cards. Some cards may be inserted with power on, while
others require that the computer be turned off.
Ejecting a Card
1.
First, exit the application using the card.
2.
On the taskbar, left-click on the
or
.
3.
Press the slot eject button once to pop it out; then press it again
to eject the PC Card.
General Dynamics Itronix 72-0146-001
FN+F8
FN+F9
FN+F10
volume
®
volume control
®
Safely Remove Hardware
Getting Familiar With Your Computer
Audio Jacks
icon
Microphone
Speakers
