Device description

A – 10-pin DAP connector, with the following pinout:
Signal Signal
Direction Description
Reference
I
Voltage
Ground
Ground
Not Connected
Ground
B – 10-pin DAPE connector, with the following pinout:
Signal Signal
Direction Description
Reference
I
Voltage
Ground
Ground
Not Connected
Ground
Signal direction definition:
O – Output from the Active Probe to the target microcontroller
I – Input to the Active Probe from the target microcontroller
C – FNet Micro connector, that connects the Active Probe to the iC5700 BlueBox. The FNet
Micro cable is delivered with the Active Probe.
D – The indicator light provides the status of the Active Probe as follows:
Permanently green - Powered On and ready
·
to use
Blinking green – Establishing connection
·
with the Blue Box
When powering on the system, switch the iC5700 on before powering on the target
system. When powering down the system, power off the target before powering off the
iC5700!
Use only original iSYSTEM accessories for powering and connecting with the iC5700.
Consult with iSYSTEM before attempting to use any other accessory.
Signal Pin
Vref 1
GND 3
GND 5
NC 7
GND 9
10-pin DAP pinout
Signal Pin
Vref 1
GND 3
GND 5
NC 7
GND 9
10-pin DAPE pinout
Pin Signal
2 DAP1
4 DAP0
6 DAP2
8 nTRST/DAPEN
10 nRESET
Pin Signal
2 DAPE1
4 DAPE0
6 DAPE2
8 DAPEN/DAP3
10 NC
Blinking blue – Reprogramming SPLASH
·
Permanently magenta – Golden image
·
loaded and ready to use
Signal Signal
Description Direction
DAP Data I/O
DAP Clock O
Optional 2nd
I/O
Data Pin
Optional 3rd
I/O
Data Pin
Reset O
Signal Signal
Description Direction
DAP Data I/O
DAP Clock O
Optional 2nd
I/O
Data Pin
Optional 3rd
I/O
Data Pin
Not Connected
