Sample Rate: 4096/hr max.
Data Storage: 8192 readings
Data Storage Technique: (TXR™) Time Extension Recording™
Power: 9V Alkaline NEDA 1604, 6JF22, 6LR61
Battery Life Recording: 6 months continuous recording @ 25°C
Output: RS-232 via 5-pin circular connector; 1200 Bps
INDICATORS
Operation Mode Indicator: One Red LED
• Single Blink: STANDBY mode
• Double Blink: RECORD mode
• No Blinks: OFF mode
• Continuously On: Overload condition
CONTROLS
Operation Mode: Push Button,
ENVIRONMENTAL
Operating Temperature: -4 to +158°F (-20 to +70°C)
Storage Temperature: -4 to +174°F (-20 to +80°C)
Relative Humidity: 5 to 95% non-condensing
MECHANICAL
Size: 2-1/2 x 1-9/16 x 4-1/2" (63.5 x 40.64 x 114.3mm)
Maximum Conductor Size: 24" length: 8" Ø; 36" length: 12" Ø
Case: Weatherproof NEMA4X, IP65 rated
SAFETY Working Voltage: IEC 1010-1, 600V, Cat III
ORDERING INFORMATION
Simple Logger
Simple Logger
Simple Logger
Simple Logger
ACCESSORIES
Replacement 6 ft RS232 cable with DB9F........................ Cat. # 2114.27
*Reference condition: 23°C ± 3K, 20 to 75% RH, Frequency 45-3000Hz, No AC external magnetic field,
DC magnetic field ≤ 40A/m, centered conductor, battery voltage 9V ± 10%.
®
AmpFlex™ Model AL24-2500................... Cat. #2113.72
®
AmpFlex™ Model AL36-2500................... Cat. #2113.73
®
AmpFlex™ Model AL24-5000................... Cat. #2113.74
®
AmpFlex™ Model AL36-5000................... Cat. #2113.75
Simple Logger
Internal Range: Slide Switch
5
®
AmpFlex™ Current Probes
