Simple Logger

Receiving Your Shipment

Upon receiving your shipment, make sure that the contents are
consistent with the packing list. Notify your distributor of any missing
items. If the equipment appears to be damaged, file a claim immediately
with the carrier and notify your distributor at once, giving a detailed
description of any damage.

Packaging

The AmpFlex™ Current Probes include the following:
• User manual
• One 9V battery
• CD-ROM containing the Windows
download and graphic software, a generic user guide, product specific
manual and the Simple Logger
• 6 ft RS-232 cable

Specifications

ELECTRICAL
Number of Channels: 1
Current Ranges: 2
Input: AL24/36-2500 - 250/2500 Arms (internally selectable)
AL24/36-5000 - 500/5000 Arms (internally selectable)
Input Connection: Permanent Flexible Sensor
*Accuracy: 1%R ±1ct
Resolution:
AL24/36-2500: 250 Arms
Scale Range Maximum Input
100% 250 Arms
50% 125 Arms
25% 62.5 Arms
12.5% 31.25 Arms
AL24/36-5000: 500 Arms
Scale Range Maximum Input
100% 500 Arms
50% 250 Arms
25% 125 Arms
12.5% 62.5 Arms
®
AmpFlex™ Current Probes
Resolution
1 Arms
0.5 Arms
0.25 Arms
0.125 Arms
Resolution
2 Arms
1 Arms
0.5 Arms
0.25 Arms
®
98, ME, 2000 and NT
®
catalog.
AL24/36-2500: 2500 Arms
Scale Range
100%
50%
25%
12.5%
AL24/36-5000: 5000 Arms
Scale Range
100%
50%
25%
12.5%
4
Maximum Input Resolution
2500 Arms
1250 Arms
625 Arms
312.5 Arms 1.25 Arms
Maximum Input Resolution
5000 Arms
2500 Arms
1250 Arms
625 Arms
10 Arms
5 Arms
2.5 Arms
20 Arms
10 Arms
5 Arms
2.5 Arms
