Control System Fault Codes - Terex Genie ZX-135/70 Service Manual

Service Manual
Fault Codes
Error Source
Primary Ext/Ret Joystick
Primary Up/Down Joystick
Steer Joystick
204
Error Type
Value at 5.0 V Limited Speed and Direction frozen at
zero and neutral, Alarm sounds
Value Too High
Value Too Low
Value at 0 V
Not calibrated Joystick Speed and Direction frozen at
zero and neutral
Just calibrated Initiate one second beep of audible
warning device
Value at 5.0 V Limited Speed and Direction frozen at
zero and neutral, Alarm sounds
Value Too High
Value Too Low
Value at 0 V
Not calibrated Joystick Speed and Direction frozen at
zero and neutral
Just calibrated Initiate one second beep of audible
warning device
Value at 5.0 V Limited Speed and Direction frozen at
zero and neutral, Alarm sounds
Value Too High
Value Too Low
Value at 0 V
Not calibrated Joystick Speed and Direction frozen at
zero and neutral
Just calibrated Initiate one second beep of audible
warning device
Effects
ZX-135/70
September 2015
Recovery Actions
Check for damaged wiring to the
joystick. Check the connections to
ensure the connector terminals have
not backed out. Substitute a known
good joystick. If necessary replace and
recalibrate joystick.
Calibrate Joystick
Self-clearing (transient)
Check for damaged wiring to the
joystick. Check the connections to
ensure the connector terminals have
not backed out. Substitute a known
good joystick. If necessary replace and
recalibrate joystick.
Calibrate Joystick
Self-clearing (transient)
Check for damaged wiring to the
joystick. Check the connections to
ensure the connector terminals have
not backed out. Substitute a known
good joystick. If necessary replace and
recalibrate joystick.
Calibrate Joystick
Self-clearing (transient)
Part No. 218700
