September 2015
Steer and Axle Manifold, continued
The steer and axle manifold is mounted inside the manifold box at the yellow triangle side of the machine.
Index
Description
No.
16
Pressure reducing valve, 2400 psi / 165 bar
17
Check valve
18
Flow control valve, 1.5 gpm / 5.7 L/min
19
Check valve
20
Flow control valve, 1.5 gpm / 5.7 L/min
21
Flow control valve, 1.5 gpm / 5.7 L/min
22
Flow control valve, 2.1 gpm / 8 L/min
23
Flow control valve, 2.1 gpm / 8 L/min
24
Solenoid valve, 3 position 4 way
25
Solenoid valve, 3 position 4 way
Part No. 218700
Schematic
Item
P
Axle extend/retract circuit
U
Prevents left rear steer cylinder
from moving when not steering
N
Left rear steer cylinder retract
circuit
W
Prevents right rear steer cylinder
from moving when not steering
O
Right rear steer cylinder retract
circuit
L
Left front steer cylinder retract
circuit
H
Left front steer cylinder extend
circuit
I
Right front steer cylinder extend
circuit
A
Steer left/right, left front steer
cylinder
B
Steer left/right, right front steer
cylinder
ZX-135/70
Service Manual
Manifolds
Function
30-35 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
20-25 ft-lbs /
Torque
41-47 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
27-34 Nm
179
