3 Install the bolt that was just removed into the
anchor hole to secure the engine pivot plate
from moving.
Crushing hazard. Failure to
install the bolt into the engine
pivot plate to secure it from
moving could result in death or
serious injury.
4 Inspect the following areas for burnt, chafed,
corroded pinched and loose wires:
• Engine wiring harness
• Battery area wiring
5 Open the ground controls side turntable cover.
6 Inspect the following areas for burnt, chafed,
corroded pinched and loose wires:
• Inside of the ground control box
• Hydraulic manifold wiring
• Battery area wiring
• Hydraulic oil cooler wiring
7 Inspect for a liberal coating of dielectric grease
in the following locations:
• All wire harness connectors to ground
control box
• Wire harness connectors to SCON module
8 Open the hydraulic manifold box covers at
both sides of the drive chassis.
9 Inspect the following areas for burnt, chafed,
corroded pinched and loose wires:
• Hydraulic manifold wiring
10 Inspect for a liberal coating of dielectric grease
in the following locations:
• Wire harness connectors to DCON module
Part No. 218700
Checklist B Procedures
11 Start the engine from the ground controls and
raise the secondary boom above the turntable
covers.
12 Inspect the turntable area for burnt, chafed
and pinched cables.
13 Lower the secondary boom to the stowed
position and turn the engine off.
14 Inspect the following areas for burnt, chafed,
corroded pinched and loose wires:
• Cable track on the boom
• Cables on the boom, jib boom and jib boom
pivot area
• Jib boom/platform rotate manifold
• Platform control box
• Inside of the platform control box
15 Inspect for a liberal coating of dielectric grease
in the following locations:
• All wire harness connectors to platform
control box
16 Remove the engine pivot plate retaining
fastener from the engine pivot plate anchor
hole at the pivot end of the engine pivot plate.
17 Swing the engine pivot plate in towards the
machine.
18 Install the bolt that was just removed into the
original hole to secure the engine pivot plate.
ZX-135/70
Service Manual
Component damage hazard. Be
sure the hydraulic supply hoses
to the function and drive pumps
are not kinked before starting the
engine.
Crushing hazard. Failure to
install the bolt into the engine
pivot plate to secure it from
moving could result in death or
serious injury.
