Recessed Mounting - StarTech.com FPWTLTB1 User Manual

Use a Phillips Head Screwdriver to tighten the screws. Do
6.
not over-tighten the screws.
Note: If you encounter resistance, stop tightening. Failure to
do so could result in damage to the TV.

Recessed Mounting

Determine the depth and diameter of the mounting holes
1.
located on the back of the TV.
Once you determine the correct depth and diameter of the
2.
hardware needed.
Place the Spacers (depending on your TV configuration)
3.
over the Screw Holes on the back of the TV.
Note: Refer to the
hardware combinations.
Align one of the Vertical Brackets (with the Adjustment
4.
Knob facing outward) with the Mounting Holes of the back
of the TV.
Place a Rectangular Washer over the Screw Holes on the
5.
Vertical Bracket.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Spacer Combination
20
table for different
