EVALUATION BOARD HARDWARE

DEVICE DESCRIPTION

The AD7761 is an 8-channel, simultaneously sampling, Σ-Δ
ADC. The AD7761
sampling. The ADC power scaling is as required for the
application, catered for by selecting one of the following modes
of operation:

Fast: 256 kSPS maximum, 110.8 kHz input bandwidth,
52 mW per channel

Median: 128 kSPS maximum, 55.4 kHz input bandwidth,
28 mW per channel

Focus: 32 kSPS maximum, 13.8 kHz input bandwidth,
9.5 mW per channel
The AD7761 offers extensive digital filtering:

Wideband: low ripple, antialiasing, low-pass filter with
sharp roll off, and full attenuation at Nyquist frequency.

Sinc response: sinc5 filter, low latency path for dc
measurements or control loops.
Table 1. Default Link and Solder Link Options
Link No. Default Option
LK1 A
LK2 B
SL1 A
SL2 B
SL3 A
SL4 A
SL4A A
SL5 Soldered 0 Ω resistor
SL6 A
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
offers an ADC per channel and synchronized
Description
LK1 selects the input voltage source.
Position A: J3 is selected.
Position B: J1 is selected.
LK2 selects the input from
Position A: 12 V input from EVAL-SDP-CH1Z.
Position B: external power supply from either J1 or J3.
SL1 selects between pin mode and SPI mode operation of the AD7761.
Position A: SPI mode.
Position B: pin mode (pin mode is not compatible with the evaluation software and currently
untested on the evaluation board).
FORMAT0 pin.
Position A: IOVDD.
Position B: DGND.
FORMAT1 pin.
Position A: DGND.
Position B: IOVDD.
Clock terminal source selection. To choose the Y1 crystal oscillator, do not populate SL4. R253,
R254, C46, and C45 must be populated. SL4A must be configured to the crystal oscillator.
Position A: selects CMOS Oscillator Y2.
Position B: unpopulated terminals (J6 and J7).
Position C: SDP MCLK.
Clock select (CLK_SEL) pin.
CMOS clock option on Pin 32.
Crystal oscillator or LVDS option.
Shorts SYNC_OUT to SYNC_IN to allow sync pulses on START to be synchronously applied to SYNC_IN.
Pin 16: ST0/CS.
Position A: chip select (CS) pin in SPI mode.
Position B: Channel 0 to Channel 3 in standby mode (pin mode).
Position C: Channel 0 to Channel 3 enabled (pin mode).
Within these filter options, the user can select a decimation rate
of 32, 64, 128, 256, 512, or 1024.
Embedded analog functionality on each ADC channel simplifies
system design. A precharge buffer on each analog input reduces
analog input current.
Complete specifications for the
product data sheet and should be consulted in conjunction with
this user guide when using the evaluation board. Full details
about the EVAL-SDP-CH1Z
Devices, Inc., website.

HARDWARE LINK OPTIONS

The default link options are listed in Table 1. The board can be
configured to operate from a bench top power supply via
Connector J3, or from a 9 V dc adapter via Connector J1. The
supply required for the
dropout regulators (LDOs), which generate their input voltage
from J1 or J3, depending on the setting of LK1. Alternatively,
the board can be powered by setting LK2 to Position A when used
in conjunction with the
EVAL-SDP-CH1Z board.
Rev. 0 | Page 5 of 17
UG-949
AD7761 are provided in the
are available on the Analog
AD7761 comes from the on-board low
EVAL-SDP-CH1Z (see Table 3 for details).
