NetVanta 7100 Administrator's Guide
4. Select the
Phone Type
may not be necessary. If configuring an
, skip to Step 8.
User
• The three different phone types that can be defined for voice users are listed below:
SIP
Analog Station
Virtual
5. Enter the phone
601) for a SIP account. If
necessary. Leave the selection as
6. Select a model from the
7. When creating an Analog Station user account, only select the
analog device.
8. Select to add the user. Additional voice settings can be configured by selecting the user's
Apply
last name in the
Setting and Changing Passwords on page 29.

Connect the Phones

ADTRAN/Polycom IP phones are configured automatically from the NetVanta 7100, which allows global
and per-phone configuration to be managed centrally. Most configuration files are created automatically
(and downloaded by the phones at boot up) by the NetVanta 7100 when a new voice user is created. Once
you have created the new user, the final step is to connect the phone.
1. Connect the phone to a line from the NetVanta 7100 system.
2. Wait for the phone to load its configuration files from the NetVanta 7100 system.
3. The phone and user account should be fully functioning.
The boot process is complete when the idle display (see Figure 7) is shown on the phone. In the case of
problems, contact your system administrator to assist with troubleshooting.
61200796L1-31A
. Based on the type of phone that will be used, some of the following steps
user accounts are associated with a SIP port.
users are associated with a physical FXS interface.
user accounts are not associated with a physical port.
if setting up a specific phone model (such as SoundPoint IP 501 or
MAC Address
is chosen for the
Other
<Not Set>
drop-down list.
Phone Model
section. This brings up the
Modify/Delete User

Figure 7. Phone Idle Display
