NetVanta 3000 Series Routers Hardware Installation Guide 1202860L1 NetVanta 3200 Unit 1200870L1 NetVanta 3205 Unit (AC Version) 1200980L1 NetVanta 3205 Unit (DC Version) 1200880L1 NetVanta 3305 Unit 1200861L1 NetVanta 56K/64K Network Interface Module 1200862L1 NetVanta T1/FT1 Network Interface Module 1200863L1...
Page 2
To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Safety Instructions NetVanta 3000 Series Hardware Installation Guide Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: 1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
Page 5
Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected or it is certain the equipment is not malfunctioning.
Page 6
FCC Radio Frequency Interference Statement NetVanta 3000 Series Hardware Installation Guide FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 7
NetVanta 3000 Series Hardware Installation Guide Industry Canada Compliance Information Industry Canada Compliance Information Notice: The Industry Canada label applied to the product (identified by the Industry Canada logo or the “IC:” in front of the certification/registration number) signifies that the Industry Canada technical specifications were met.
Page 8
Affidavits NetVanta 3000 Series Hardware Installation Guide Affidavits Affidavit Requirements for Connection to Digital Services • An affidavit is required to be given to the telephone company whenever digital terminal equipment without encoded analog content and billing protection is used to transmit digital signals containing encoded analog content which are intended for eventual conversion into voiceband analog signals and transmitted on the network.
Page 9
NetVanta 3000 Series Hardware Installation Guide Affidavits Affidavit for Connection Of Customer Premises Equipment to 1.544 Mbps And/or Subrate Digital Services For the work to be performed in the certified territory of ___________________(telco name) State of ________________ County of ________________...
NetVanta 3000 Series Hardware Installation Guide Warranty and Customer Service ADTRAN will repair and return this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at: http://support.adtran.com...
Page 11
Your reseller should serve as the first point of contact for support. If additional pre-sales support is needed, the ADTRAN Support web site provides a variety of support services such as a searchable knowledge base, latest product documentation, application briefs, case studies, and a link to submit a question to an Applications Engineer.
Page 12
These courses include overviews on product features and functions while covering applications of ADTRAN's product lines. ADTRAN provides a variety of training options, including customized training and courses taught at our facilities or at your site. For more information about training, please contact your Territory Manager or the Enterprise Training Coordinator.
INTRODUCTION TO THE NETVANTA SOLUTION The NetVanta 3000 Series is a line of modular access routers designed for cost-effective branch office connectivity over frame relay or point-to-point (PPP) networks. These modular platforms offer a complete solution for access routing and WAN connectivity in a single, compact package.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (see Warranty and Customer Service on page 10).
Page 21
Shipments of the 56K/64K NIM include the following items: • 56K/64K Network Interface Module • Quick Start Guide • 6-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3127004) NetVanta T1/FT1 NIM (1200862L1 and 61202862L1) Shipments of the T1/FT1 NIM include the following items: • T1/FT1 Network Interface Module •...
Page 22
Shipments of the T1 NIM include the following items: • Dual T1 Network Interface Module • Quick Start Guide • Two 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A) NetVanta E1/FE1 NIM (1200868L1) Shipments of the E1/FE1 NIM include the following items: • E1/FE1 Network Interface Module •...
Page 23
NetVanta 3000 Series Hardware Installation Guide Introduction to the NetVanta Solution NetVanta VPN Accelerator Card (1202368L1) Shipments of the VPN Accelerator Card include the following items: • VPN Accelerator Card • Quick Start Guide Option modules are intended to be serviced by qualified service personnel only.
Physical Description NetVanta 3000 Series Hardware Installation Guide PHYSICAL DESCRIPTION Reviewing the Base Unit Front Panel Designs Figure 1 shows the NetVanta 3200 front panel. Figure 1. NetVanta 3200 Front Panel Layout Figure 2 shows the NetVanta 3205 front panel.
NetVanta 3000 Series Hardware Installation Guide Physical Description Front Panel LEDs Table 1 describes the front panel LEDs. Table 1. NetVanta 3000 Series LEDs For these This activity… Indicates that… LEDs… STATUS The unit is powering up. On power-up the STAT LED blinks rapidly for...
Physical Description NetVanta 3000 Series Hardware Installation Guide Reviewing the Rear Panel Design Figure 4 through Figure 7 show the rear panels for theNetVanta 3000 Series. Each chassis is shown with the T1/FT1+DSX-1 NIM installed. The Activity and Link LEDs, which are present on all NetVanta Ethernet ports, are pointed out in Figure 4.
NetVanta 3000 Series Hardware Installation Guide Physical Description Rear Panel Interfaces and LEDs 10/100BaseT Ethernet Interface and Activity LEDs The Ethernet port (ETH 0/1) is an RJ-48C connector with LEDs. The yellow activity LED flashes when data traffic is being sent or received on the Ethernet port. The green link LED is on when the router has a good connection to the LAN.
NetVanta 3000 Series Hardware Installation Guide OPTION MODULES The NetVanta 3000 Series accepts several option modules designed to meet a variety of networking requirements. The option modules are of two types: plug-in Network Interface Modules (NIMs) and plug- on Dial Backup Interface Modules (DIMs).
NetVanta 56K/64K NIM (P/N 1200861L1) The 56K/64K NIM (shown in Figure 8) provides a WAN interface for the NetVanta 3000 Series. This module provides a single 56K or 64K DDS network interface. Refer to Table A-5 on page 53 for the WAN- DDS connector pinout, and refer to Table A-12 on page 56 for the DBU connector pinout.
Option Modules NetVanta 3000 Series Hardware Installation Guide NetVanta T1/FT1 NIM (P/N 1200862L1 and 1202862L1) The T1/FT1 NIM (shown in Figure 9) provides a T1 (full or fractional) WAN interface for the NetVanta 3000 Series. Refer to Table A-6 on page 53 for the WAN-T1 connector pinout, and refer to Table A-12 on page 56 for the DBU connector pinout.
NetVanta T1/FT1+DSX-1 NIM (P/N 1200863L1 and 1202863L1) The T1/FT1 + DSX-1 NIM (see Figure 10) provides a T1 WAN interface for the NetVanta 3000 Series. The T1/FT1 + DSX-1 NIM provides a full T1 or fractional T1 network interface and a DSX-1 interface.
NetVanta Dual T1 NIM (P/N 1200872L1) The NetVanta Dual NIM (see Figure 11) provides two WAN T1 interfaces for the NetVanta 3000 Series. Refer to Table A-5 on page 46 for the pinouts. Refer to Table A-13 on page 56 for the DBU connector pinout.
NetVanta 3000 Series Hardware Installation Guide Option Modules NetVanta T1 NEBS NIM (P/N 1200862L2#NEBS) The T1 NEBS NIM (see Figure 12) provides a T1 WAN interface for the NetVanta 3205 DC. The T1 NEBS NIM provides a full T1 or fractional T1 network interface. Refer to Table A-6 on page 53 for the WAN-T1 connector pinout.
The NetVanta Serial NIM (shown in Figure 13) is user-configurable to be either a V.35 or X.21 (V.11) interface. This module supports rates up to a maximum of 10 Mbps. An additional V.35 (ADTRAN P/N 1200873L1) or X.21 (ADTRAN P/N 1200874L1) cable is required (see Caution, below). Refer to...
NetVanta 3000 Series Hardware Installation Guide Option Modules NetVanta SHDSL NIM (P/N 1200867L1) The NetVanta SHDSL NIM (shown in Figure 14) provides a WAN SHDSL interface for the NetVanta. Refer to Table A-10 on page 54 for the SHDSL connector pinout. Refer to Table A-13 on page 56 for the DBU connector pinout.
NetVanta 3000 Series Hardware Installation Guide NetVanta E1/FE1 NIM (P/N 1200868L1) The NetVanta E1/FE1 NIM (see Figure 15) provides a WAN-E1 interface for the NetVanta 3000 Series meeting the requirements of ITU-T G.703/G.704. The module provides a single 2.048 Mbps network interface.
NetVanta 3000 Series Hardware Installation Guide Option Modules NetVanta E1/FE1 with G.703 Drop NIM (P/N 1200878L1) The NetVanta E1/FE1 with G.703 Drop NIM (see Figure 16) provides a single WAN-E1 interface (2.043 Mbps) with user-selectable TS0 assignment and a G.703 drop port which may be used to drop and insert traffic to an E1 PBX.
NetVanta Analog Modem DIM (P/N 1200864L1) The Analog Modem DIM provides a modem with data rates up to 33.6 kbps for the NetVanta 3000 Series. This DIM is a plug-on card that connects to the NIM. For installation instructions, see Installing Dial Backup and Network Interface Modules on page 47.
The NetVanta ISDN BRI DIM provides dial backup access to the public switched telephone network (PSTN) via Basic Rate ISDN for the NetVanta 3000 Series. This DIM is a plug-on module that connects to the NIM. For installation instructions, see Installing Dial Backup and Network Interface Modules on page 47.
The NetVanta ISDN S/T DIM provides dial backup access to the public switched telephone network (PSTN) via Basic Rate ISDN for the NetVanta 3000 Series. This DIM is a plug-on module that connects to the NIM. For installation instructions, see Installing Dial Backup and Network Interface Modules on page 47.
For information on router configuration for a specific application, refer to the quick start documents provided on your ADTRAN OS Documentation CD. For details on the command line interface, refer to the AOS Command Reference Guide (also included on your CD).
Step Action Position the NetVanta 3000 Series in a stationary equipment rack. This unit takes up 1 U of space. To allow proper grounding, scrape the paint from the rack around the mounting holes where the NetVanta 3000 Series will be positioned.
NetVanta 3000 Series Hardware Installation Guide Unit Installation Wall Mounting NetVanta 3000 Series NetVanta 3200 Instructions for Wall Mounting NetVanta 3200 Step Action Decide on a location for the NetVanta 3200. Keep in mind that the unit needs to be mounted at or below eye-level so that the LEDs are viewable.
Unit Installation NetVanta 3000 Series Hardware Installation Guide NetVanta 3205 and NetVanta 3305 Instructions for Wall Mounting NetVanta 3205/NetVanta 3305 Step Action Remove the mounting ears. Rotate them 90 so that the portion of the bracket with the mounting holes is flush with the bottom of the chassis, and reattach them to the chassis (see Figure 18).
As shipped, each NetVanta 3000 Series is set to factory default conditions. After installing the base unit and any option modules, the NetVanta 3000 Series is ready for power-up. To power-up the unit, ensure that the unit is properly connected to an appropriate power source (as outlined in the sections which follow).
Page 46
Unit Installation NetVanta 3000 Series Hardware Installation Guide •Power to the NetVanta 3205 DC System must be from a reliably grounded +24 or -48 VDC source which is electrically isolated from the AC source. •Use only copper conductors when making power connections.
NetVanta 3000 Series Hardware Installation Guide Unit Installation Installing Dial Backup and Network Interface Modules The DIMs plug on to the NIMs. The NIMs are then installed in the rear panel option module slot. The following tables list the installation steps. Also see Figure 19 below and Figure 20 on page 48.
WAN-DDS Figure 20. NIM and DIM Installation Your NetVanta 3000 Series is now ready to be configured and connected to the network. For more information on configuration for a specific application, refer to the quick start documents provided on your ADTRAN OS Documentation CD.
NetVanta 3000 Series Hardware Installation Guide Unit Installation Installing the NetVanta VPN Accelerator Card (1202368L1) The optional VPN Accelerator Card plugs into a 32-bit PCI slot and is designed to be used in the NetVanta 3305 to provide encryption/decryption and security acceleration services. The card provides the following security services to the host processor: DES, Triple-DES, AES, SHA-1, MD5, and Random Number Generation.
Appendix A. Connector Pin Definitions NetVanta 3000 Series Hardware Installation Guide Table A-3. Console Port (DCE) Pinout for NetVanta 3200 (p/n 1202860L1) Name Description Data Carrier Detect (output) Receive Data (output) Transmit Data (input) Data Terminal Ready (input) Signal Ground Data Set Ready Tied to pin 1 (output) —...
NetVanta 3000 Series Hardware Installation Guide Appendix A. Connector Pin Definitions Network Interface Module (NIM) Pinouts WAN Connectors Table A-5. WAN-DDS Connector Pinouts Name Description Transmit data to the network–Ring 1 Transmit data to the network–Tip 1 — Unused Receive data from the network–Tip Receive data from the network–Ring...
Appendix A. Connector Pin Definitions NetVanta 3000 Series Hardware Installation Guide Table A-8. DSX-1 Connector Pinouts Name Description Transmit data toward the DTE–Ring Transmit data toward the DTE–Tip — Unused Receive data from the DTE–Ring 1 Receive data from the DTE–Tip 1 —...
