Debug Device - HikRobot X86 Open Platform Quick Start Manual

Attribute
Device Control
Image Setting
Light Source Control
Trigger and IO Control
Communication Control
User Set Control
Debug Info.
For specific attributes, please refer to the actual device you got.

4.3 Debug Device

Follow steps below to debut device via MVS client.
Steps:
1. Go to Trigger and IO Control, and set Trigger Mode as Off.
By default, the Trigger Mode is On, and there will be no image during live view.
2. After the live view is available, adjust lens aperture, focus, exposure time, gain, etc. based on
the live view image effect.
3. Save the edited settings to the user parameters, and set the default parameters as the saved
user parameters, to prevent device attributes from being restored after restart.
 Save Parameters: Click User Set Control, and select a user set in User Set Selector. Click
Execute in User Set Save to save parameters.
X86 Open Platform
·
Table 4-2 Attribute Description
Description
You can view device information, edit its name and
reset the device.
You can view device's frame rate, and set exposure,
gain, brightness, Gamma, etc.
You can view and set related parameters of supplement
light.
You can view and set device's debugging information.
You can view and set data communication method.
You can save or load the device's parameters, set the
default parameters when running the software, confirm
certain information via two user indicators.
You can view device running time, etc.
19
Quick Start Guide
