Chapter 2 Device Installation; Accessory; Install And Change Lens - HikRobot X86 Open Platform Quick Start Manual

2.1 Accessory

You need to prepare following accessories before installation.
No. Name
1 Power and I/O cable
2 Network cable
Interface expansion
3
cable
Interface expansion
4
module
DC switching power
5
supply
6 Lens
7 Mounting bracket
8 Waterproof lens cover

2.2 Install and Change Lens

Follow steps below to install or change lens.
Steps:
1. Screw out the waterproof lens cover, and take out the lamp cup.
2. Install the required C-mount lens to the device, or change the lens.
3. Reinstall the lamp cup and the lens cover again.
X86 Open Platform

Chapter 2 Device Installation

Table 2-1 Recommended Accessories
Quantity Description
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
Quick Start Guide
·
It refers to the 12-pin power and I/O cable.
It refers to the RJ45 network cable with
aviation connector.
It refers to the interface expansion cable.
It refers to the interface expansion module.
Power adapter above 12 VDC, 2 A or 24
VDC, 1 A.
It refers to C-mount lens.
It is used to fix the device.
It is used to protect lens and light source.
