Kimball Office Fluent Assembly Instructions

Fluent
Modesty Panels
Tools Required
Pencil
9 ⁄ " Allen Tool
64
Tape Measure
Package Contents
Resin Modesty
Bracket
#8 x 3 ⁄ " 8-32 UNC
4
Panhead Screw Set Screw
Installation
Resin Modesty panel:
1. Slide bracket onto resin modesty panel and tighten all set
screws. (Figure A).
2. Align modesty panel centered left to right (approximatley
1 1 ⁄ " on both sides), to dimension shown front to back with
2
worksurface, measure and mark hole locations. (Figure B).
3. Drill pilot holes to insure modesty is mounted perpendicular
to surface. Attach modesty panel assembly to worksurface as
shown. (Figure C).
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 2205354 Revision B-09
Screw Gun
#2 Phillips Head Bit
Fixed Modesty Technology Modesty
"L" Bracket
#8 x 3 ⁄ " #8 x 1"
4
Panhead Screw Panhead Screw
Figure A
Figure B
Hinge
Figure C
Assembly Instructions
Page 1 of 2
5 1 ⁄ " max. Worksurface
2
1" min.
Modesty Panel
Pre-Drill Pilot Holes
Prior to Fastening Screws
9 ⁄ " Allen Tool
64
