Kimball Office Itsa K38AA Adjustment Instructions

Kimball Office Itsa Adjustment Instructions
Model: K38AA & K38CC (Knee Tilt - 1.0 & 2.0 models)
Height Adjustment
1. Handle is located under seat on right side as seated towards the front of the chair. Pull up on handle
to adjust seat height. Release the handle when desired height is attained.
Tilt/Tilt Lock
1. Handle for tilt lock is same handle as the height adjustment handle, again, under right side of seat.
Push this handle in to lock the chair from tilting and pull it out to allow the chair to tilt. When pushing
this handle in and pulling it out a click can be heard to help indicate it is in either position.
Tilt Tension
1. When chair is in tilting mode, the tension knob can adjust the tension to fit occupant's size. This knob
is a large black plastic knob and located under the center of the seat towards front. Turning the knob
counter clockwise will increase the tension and clockwise will decrease the tension.
Seat Slide (for seat slide models only)
1. Handle for seat slide option is located under seat on the left side towards the front. To operate the
seat slide, pull lever up while manually adjusting the seat depth. When the desired seat depth is
attained, release the adjustment handle and the chair will lock into that position. Note that the seat
slide mechanism is spring loaded to assist the seat in moving backward toward the chair back.
Non-Seat Slide Control
One Handle
Seat Slide Control
Two Handles
