Kimball Office Fluent Assembly Instructions

Fluent

Highback Shelf

Tools Required

Scissors

Package Contents

Felt
Doudle Sided
Adhesive Tape

Installation

Note: It is recommended that two (2) persons be used to lift
and flip highback shelf units.

Without Workwall

1. Place the shelf on a clean, soft surface, underside
facing up. Align leg assembly centered front to back
and press flush up against edge of pan. Attach legs using
nine (9) #10 x 1" panhead screws provided. (Figure A).
2. The wire manager is attached with double-sided adhesive
tape. Peal off film backer from tape and apply wire manager
to inside of leg. To securely attach a highback shelf to a
worksurface, cut four pieces of double-sided adhesive tape
and place on bottom of all four legs. Remove the film
backer to expose the adhesive. (Figure B).
3. Flip assembled highback right side up and place on desk
unit. (Figure C).
Note: The worksurface MUST be clean, dry, and free of any
dirt or residue to assure adequate adhesion.
Caution: The tape is a very strong adhesive and bonds
instantly to any surface it is applied to.
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call Kimball Office Customer Service.
Part No. 2205357 Revision B-10
Screw Gun
#2 Phillips Head Bit
#10 x 1"
Panhead Screw
Figure A
Press Leg Assemby
Flush against Pan
Pan
Figure B
Peel off
film backer
Wire
Manager
Figure C
Assembly Instructions
Page 1 of 2
Leg Assembly
Slight Offset
Shelf
