PRESSURE REDUCING VALVE (PRV) CONFIGURATION

1.3.1

METHOD OF OPERATION

1.3.2 P&ID
Item Description
1 Upstream (inlet)
2 Downstream (outlet)
3 Control block
4 Pilot supply
5 Pilot outlet connection
Item Description
Pressure reducing
1
pilot
2 Strainer
3 Restrictor
4 Isolation ball valve
5 Speed Control Valve
6 IP Valve
7
