1.4 PRESSURE RATINGS & PERFORMANCE
Maximum upstream pressure
Downstream pressure range
Minimum Pressure Drop
*With medium temperature ≤ 20°C; >20°C on request
**Pilot dependent
***Flow rate & size dependent
1.5 FLANGE & SIZING DATA
Nominal Pipe
Dimension
DN200 DN200 / 8"
DN250 DN250 / 10"
DN300 DN300 / 12"
Flange compatibility
Diameter
PN10 / PN16 / ANSI150
PN10 / PN16 / ANSI150
PN10 / PN16 / ANSI150
16 bar*
0.1-16 bar**
0.1 bar***
Kv Cv
3
(m /hr) (USGal/min)
565 653
773 894
1004 1161
