1.10 BILL OF MATERIALS – PRESSURE REDUCING PILOT (PR1)
Item
Description
No.
301 PR1 Pilot Base
302 Diaphragm Housing
303 Spring Case
304 Diaphragm Support
305 Actuator
306 Upper Spring Guide
307 Diaphragm
308 G1/4 Pilot base plug
309 Pilot setpoint bolt (60mm)
310 PR1 Pilot Nameplate Sticker
311 Pilot Primary Spring
312 Pilot Actuator Spring
313 Pilot Diaphragm Bolt
314 Pilot base seal
315 Pilot base plug seal
316 M6 Flanged torque nut
M6 x 40 Socket head bolt – A2-70
317
M10 Thin Hex Nut – A2-70 SS
318
M10 Spring colour indication
319
washer – Plastic/A2 SS
320 Actuator Pin
∅3 x 10mm ISO8750 Roll pin – A1
321
Quantity
SS
SS
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8
1
1
1
2
15
