Assembly Guide - Wren Kitchens BASE UNIT 600 Assembly Manual

BASE UNIT
600 - 1000 Sink/Hob
1/2 Door

Assembly Guide

Panel A
x1 Back Panel
(800 - 1000 folded)
(F) x8
Wooden Dowel
REQUIRED TOOLS
Page 1
sink rail +
screws
600 - *off
800 - *off
1000 - *off
Panel B
x2 End Panel
Legs
x4 or 5
as req'd
(G) x6 (H) x6 (K) x4
30mm
Cam Dowel Cam Lock
(Expanding) Screw
NOT to be used
with CAM DOWEL
& CAM LOCK
For Internal Use: FI.WR.INS.057_WKIN00145_BASE_600-1000_1-2Dr_Sink/Hob_Rev2.indd
Panel C Panel E
x1 Base Panel x1 Rail
Hinge Mounting Plate
x4 Inc Screws
(L) x12 (M) x4
Cover
15mm
Screw Cap
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
fi.pk.
fit.141
Shelf Sink Frontal
x1 Rail (Packed separately)
x1 x1 or 2
as req'd
Hinge
x4 Inc Screws
(N) x2 (Z) x4
Door Shelf Peg
Buffer plastic
