BASE UNIT
600 Built Under Oven Housing Assembly Guide
For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vogue BASE UNIT 600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wren Kitchens Vogue BASE UNIT 600

Summary of Contents for Wren Kitchens Vogue BASE UNIT 600

  • Page 1 BASE UNIT 600 Built Under Oven Housing Assembly Guide For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd...
  • Page 2 BASE UNIT 600 Built Under Oven Housing Assembly Guide BEFORE YOU START INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel E Legs Panel B Panel C Filler F Filler G x2 Rail Panel x2 End Panel x1 Base Panel...
  • Page 3 Step 1. Step 2. Seat dowel (F) Seat cam dowel (G) into into holes in holes in both end panels (B) Seat (G) cam dowel both end panels (B) as shown. into hole as as shown. shown. Dowel (F) & Cam Dowel (G) location detail Step 3.
  • Page 4 BASE UNIT 600 Built Under Oven Housing Assembly Guide 50mm Front 85mm Leg position diagram Step 5. Secure each of the legs into place with 4 x 15mm screws (L) as shown. Step 6. Push leg firmly down into leg base. Adjust legs to 155mm before turning unit upright.
  • Page 5 Filler F L Bracket Filler G Step 7. Use 1 x 15mm screw (L) per L Bracket SML (FF) to secure to inside face of Filler (G). Attached equally spaced as shown. From Top 24 mm Inside Face inside face 155mm 155mm Step 8.
  • Page 6 BASE UNIT 600 Built Under Oven Housing Assembly Guide Securing To Adjacent Units Screw into any side units using the 30mm screws (K) provided to secure to unit. Screw at the top and bottom of both sides of the unit, place a cover caps (M) on the head to conceal it.
