Wren Kitchens BASE UNIT 1000 Assembly Manual

2 door
Hide thumbs Also See for BASE UNIT 1000:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
BASE UNIT
1000 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.022_WKIN00104_BASE_1000_2Door_Rev3.indd

Advertisement

loading
Need help?

Need help?

Do you have a question about the BASE UNIT 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Wren Kitchens BASE UNIT 1000

Summary of Contents for Wren Kitchens BASE UNIT 1000

  • Page 1 BASE UNIT 1000 2 Door Assembly Guide For Internal Use: FI.WR.INS.022_WKIN00104_BASE_1000_2Door_Rev3.indd...
  • Page 2 BASE UNIT BEFORE YOU START 1000 2 Door INSTALLATION SHOULD BE PERFORMED BY A Assembly Guide COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Legs Panel A Panel B Panel C Panel D Panel E Shelf Frontal x1 Muntin x1 Back Panel (Folded) x2 End Panel...
  • Page 3 BASE UNIT 1000 2 Door Seat (G) Assembly Guide Step 1. cam dowel Seat dowel (F) into holes in into hole as shown. both end panels (B) as shown. Step 2. Seat cam dowel (G) into holes in both end panels (B) as shown. Dowel (F) &...
  • Page 4 BASE UNIT 1000 2 Door Assembly Guide Step 5. Slide back panel (A) into groove of end panels (B). Once back panel (A) is in position, ensure the panel is flush & square with bottom of end panels (B). Step 6. Hand tighten all cam locks (H), this will expand cam dowels (G) and tighten the unit together.
  • Page 5 BASE UNIT 1000 2 Door Front Assembly Guide Step 9. Secure each of the legs into place with 2 x 15mm screws (L) per leg. Ensure legs are rotated as shown so that part of it is supporting the end panels (B). Front legs should have flat edge to the front.
  • Page 6 BASE UNIT from top 1000 2 Door 94mm Assembly Guide 126mm Hinge Plates Step 12. Attach Hinge Mounting Plate 126mm onto both End Panel or panels,(B) as shown, using Screws 94mm which are already positioned within the Hinge Plates. Hinge side or sides to be mounted in accordance to customer kitchen plan.
  • Page 7 BASE UNIT 1000 2 Door Step 13. Assembly Guide Insert hinge in top & bottom holes as shown. Step 14. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges. Step 15. Attach the door to unit where required.
