Pre-Installation And Application Warnings; Installation; Wiring Diagram With T-Harness (Thniss3/Thniss3D) - Automatic Transmission - Directed Directechs DB3 Installation Manual

Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
The optional Plug & Play THNISS3/THNISS3D T-Harnesses are sold separately.
Š
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
Š
connector.
Refer to "Vehicle connections" following the wiring diagram.
Š
General notes: This section highlights important information for this specific firmware.
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[1]
This connection is ONLY required if the feature does not operate in data.
[2]
5
403.NISS3HT 3.09 2009 Nissan Altima (Smart Key)
