Wiring diagram with T-Harness (THNISS3/THNISS3D)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Clock & Data Wire
at Key Port Connector
Refer to the Vehicle wiring
reference charts for wire
location.
(+) 12V Input
(AC) Tach Input
(-) Ground
(+) Ignition Input
(+) Starter Output
Clutch Bypass,
pin1
86 87
87a
Clutch Bypass,
pin2
Clutch
2 Pedal
1
1
Clutch Pedal 1
Clutch Pedal 2
86 87
87a
7 403.NISS3HT 3.09 2009 Nissan Altima (Smart Key)
© 2020-08-12 Directed. All rights reserved.
with manual transmission
T-01
T-01
(Green connector behind instrument cluster)
20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
(-) Driver Door Trigger:
Lt.Blue,
(-) Push-to-Start:
85
30
2
B-01
Clutch
Bypass,
pin2
85
CUT
30
Connectors T-01 and T-02
(each pair has one male and
one female) are not interchangeable,
thus you will be able to connect
ONLY the correct connectors.
BCM conn.
Note: insert pin if wire is not present
pin 39
(-) RAP Off Output: Red/Black
(AC) Tach Output: Violet/White
(+) Ignition Status Input: Violet/Green
(+) Ignition Status Output: Violet/Brown
(-) Push-To-Start Output: Green/Black
Push-to-Start
(Brown conn. at Push-to-Start switch)
1 2 3
4 5 6 7 8
Brown, pin 4
NOT USED
OR
NOT USED
T-02 T-02
1
NOT USED
THNISS3/THNISS3D
(optional T-Harness)
Diagnostic Connector
B-02 OBDII
).
D2D
only
The Remote Start Safety
Override Switch is
inactive (used for RSR only)
Do not
connect
