Directed Directechs DB3 Installation Manual page 12

Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Brake Wire
Clutch Pedal
Clutch Pedal 2
12 403.NISS3HT 3.09 2009 Nissan Altima (Smart Key)
© 2020-08-12 Directed. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input [2]
(-)
(-) [3]
(-)
(+) W2W Only - Pk Light Input
(+) W2W Only - Starter Input
(+)
(-) W2W Only - Ground When Running (Status) Input
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
BCM behind instrument cluster, black 3 pin plug, pin
1
brake switch or BCM behind instrument cluster, green
40 pin plug, pin 7
front clutch switch, brown 2 pin plug, pins 1, 2
back clutch switch, brown 2 pin plug, pin 2
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
Remote Starter
Remote Starter
No Connection
Remote Starter
(+/-) Wire Color
+ white/black (40A)
+ red/green or lt. green to orange/blue
+ white (input); red (output)
cut white
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
