3.3.2 Mounting the Unit to the Work Surface
The filter flipper is normally used mounted to standard post via the 8-32 (M4) hole in
the base, as shown in Fig. 3.1.. .
Standard TR series
1/2" Post

3.4 Transportation

When packing the unit for shipping, use the original packing. If this is not
available, use a strong box and surround the unit with at least 100 mm of
8-32 (M4)
Threaded Hole
Fig. 3.1 Installation
shock absorbent material.
MFF101 and MFF102 Motorized Filter Flippers
Caution
9
